6XCX | pdb_00006xcx

Nitric Oxide Synthase from Bacillus subtilis in complex with N2-((3-((2-aminoquinolin-7-yl)methoxy)phenoxy)methyl)pyridine-2,6-diamine

PDB DOI: https://doi.org/10.2210/pdb6XCX/pdb

Classification: OXIDOREDUCTASE
Organism(s): Bacillus subtilis subsp. subtilis str. 168
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-06-09 Released: 2021-06-16
Deposition Author(s): Lewis, M.C., Poulos, T.L.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free:
0.220 (Depositor), 0.220 (DCC)
R-Value Work:
0.179 (Depositor), 0.180 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Selective Anti-MRSA inhibitors targeting Nitric Oxide Synthase

Lewis, M.C., Poulos, T.L.

To be published.

Macromolecule Content

Total Structure Weight: 43.17 kDa
Atom Count: 3,146
Modelled Residue Count: 362
Deposited Residue Count: 363
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nitric oxide synthase oxygenase	A	363	Bacillus subtilis subsp. subtilis str. 168	Mutation(s): 0 Gene Names: nos, yflM, BSU07630 EC: 1.14.14.47
UniProt
Find proteins for O34453 (Bacillus subtilis (strain 168)) Explore O34453 Go to UniProtKB: O34453
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O34453
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEC Query on HEC Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	HEME C C₃₄ H₃₄ Fe N₄ O₄ HXQIYSLZKNYNMH-LJNAALQVSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
V0P (Subject of Investigation/LOI) Query on V0P Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	7-{[3-(2-{[(6-aminopyridin-2-yl)methyl]amino}ethoxy)phenoxy]methyl}quinolin-2-amine C₂₄ H₂₅ N₅ O₂ ORKMBBJESKKJPF-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
PEG Query on PEG Download Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
POL Query on POL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A]	E [auth A], F [auth A]	N-PROPANOL C₃ H₈ O BDERNNFJNOPAEC-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
