6WUA

30S subunit (head) of 70S Ribosome Enterococcus faecalis MultiBody refinement

  • Classification: RIBOSOME
  • Organism(s): Enterococcus faecalis OG1RF
  • Mutation(s): No

  • Deposited: 2020-05-04 Released: 2020-11-04
  • Deposition Author(s): Jogl, G., Khayat, R.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Cryo-electron microscopy structure of the 70S ribosome from Enterococcus faecalis.

Murphy, E.L.Singh, K.V.Avila, B.Kleffmann, T.Gregory, S.T.Murray, B.E.Krause, K.L.Khayat, R.Jogl, G.

(2020) Sci Rep 10: 16301-16301

  • DOI: https://doi.org/10.1038/s41598-020-73199-6
  • Primary Citation of Related Structures:
    6O8W, 6O8X, 6O8Y, 6O8Z, 6O90, 6W6P, 6WU9, 6WUA, 6WUB

  • PubMed Abstract:

    Enterococcus faecalis is a gram-positive organism responsible for serious infections in humans, but as with many bacterial pathogens, resistance has rendered a number of commonly used antibiotics ineffective. Here, we report the cryo-EM structure of the E. faecalis 70S ribosome to a global resolution of 2.8 Å. Structural differences are clustered in peripheral and solvent exposed regions when compared with Escherichia coli, whereas functional centres, including antibiotic binding sites, are similar to other bacterial ribosomes. Comparison of intersubunit conformations among five classes obtained after three-dimensional classification identifies several rotated states. Large ribosomal subunit protein bL31, which forms intersubunit bridges to the small ribosomal subunit, assumes different conformations in the five classes, revealing how contacts to the small subunit are maintained throughout intersubunit rotation. A tRNA observed in one of the five classes is positioned in a chimeric pe/E position in a rotated ribosomal state. The 70S ribosome structure of E. faecalis now extends our knowledge of bacterial ribosome structures and may serve as a basis for the development of novel antibiotic compounds effective against this pathogen.


  • Organizational Affiliation

    Department of Molecular Biology, Cell Biology, and Biochemistry, Brown University, Providence, RI, 02912, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S3B [auth c]204Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q839F8 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q839F8
Go to UniProtKB:  Q839F8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ839F8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S7C [auth g]154Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q839H0 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q839H0
Go to UniProtKB:  Q839H0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ839H0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S9D [auth i]128Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q82Z47 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q82Z47
Go to UniProtKB:  Q82Z47
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ82Z47
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S10E [auth j]99Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q839G5 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q839G5
Go to UniProtKB:  Q839G5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ839G5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S13F [auth m]112Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for P59754 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore P59754
Go to UniProtKB:  P59754
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP59754
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S14 type ZG [auth n]60Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q839F1 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q839F1
Go to UniProtKB:  Q839F1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ839F1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S19H [auth s]78Enterococcus faecalis OG1RFMutation(s): 0
UniProt
Find proteins for Q839G0 (Enterococcus faecalis (strain ATCC 700802 / V583))
Explore Q839G0
Go to UniProtKB:  Q839G0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ839G0
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
16S rRNAA [auth a]1,548Enterococcus faecalis OG1RF
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.14_3235
RECONSTRUCTIONcryoSPARC0.63

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM094157
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesG12MD007603

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-04
    Type: Initial release
  • Version 1.1: 2021-05-19
    Changes: Database references
  • Version 1.2: 2024-03-06
    Changes: Data collection, Database references, Refinement description
