6WDN | pdb_00006wdn

Cryo-EM structure of mitochondrial calcium uniporter holocomplex in low Ca2+


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6WDN

This is version 1.2 of the entry. See complete history

Literature

Structure and mechanism of the mitochondrial Ca2+uniporter holocomplex.

Fan, M.Zhang, J.Tsai, C.W.Orlando, B.J.Rodriguez, M.Xu, Y.Liao, M.Tsai, M.F.Feng, L.

(2020) Nature 582: 129-133

  • DOI: https://doi.org/10.1038/s41586-020-2309-6
  • Primary Citation Related Structures:
    6WDN, 6WDO

  • PubMed Abstract:

    Mitochondria take up Ca 2+ through the mitochondrial calcium uniporter complex to regulate energy production, cytosolic Ca 2+ signalling and cell death 1,2 . In mammals, the uniporter complex (uniplex) contains four core components: the pore-forming MCU protein, the gatekeepers MICU1 and MICU2, and an auxiliary subunit, EMRE, essential for Ca 2+ transport 3-8 . To prevent detrimental Ca 2+ overload, the activity of MCU must be tightly regulated by MICUs, which sense changes in cytosolic Ca 2+ concentrations to switch MCU on and off 9,10 . Here we report cryo-electron microscopic structures of the human mitochondrial calcium uniporter holocomplex in inhibited and Ca 2+ -activated states. These structures define the architecture of this multicomponent Ca 2+ -uptake machinery and reveal the gating mechanism by which MICUs control uniporter activity. Our work provides a framework for understanding regulated Ca 2+ uptake in mitochondria, and could suggest ways of modulating uniporter activity to treat diseases related to mitochondrial Ca 2+ overload.


  • Organizational Affiliation
    • Department of Molecular and Cellular Physiology, Stanford University School of Medicine, Stanford, CA, USA.

Macromolecule Content

  • Total Structure Weight: 189.35 kDa
  • Atom Count: 12,612
  • Modeled Residue Count: 1,540
  • Deposited Residue Count: 1,614
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Calcium uptake protein 2, mitochondrial335Homo sapiensMutation(s): 0
Gene Names: MICU2EFHA1
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q8IYU8 (Homo sapiens)
Explore Q8IYU8
Go to UniProtKB:  Q8IYU8
PHAROS:  Q8IYU8
GTEx:  ENSG00000165487
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IYU8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Calcium uptake protein 1, mitochondrial363Homo sapiensMutation(s): 0
Gene Names: MICU1CALCCBARA1
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BPX6 (Homo sapiens)
Explore Q9BPX6
Go to UniProtKB:  Q9BPX6
PHAROS:  Q9BPX6
GTEx:  ENSG00000107745
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BPX6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Essential MCU regulator, mitochondrialC [auth F],
E [auth D],
G [auth H],
I [auth J]
51Homo sapiensMutation(s): 0
Gene Names: SMDT1C22orf32EMRE
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H4I9 (Homo sapiens)
Explore Q9H4I9
Go to UniProtKB:  Q9H4I9
PHAROS:  Q9H4I9
GTEx:  ENSG00000183172
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9H4I9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Calcium uniporter protein, mitochondrialD [auth C],
F [auth G],
H [auth I],
J [auth E]
178Homo sapiensMutation(s): 0
Gene Names: MCUC10orf42CCDC109A
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NE86 (Homo sapiens)
Explore Q8NE86
Go to UniProtKB:  Q8NE86
PHAROS:  Q8NE86
GTEx:  ENSG00000156026
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8NE86
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-05-27
    Type: Initial release
  • Version 1.1: 2020-06-17
    Changes: Database references
  • Version 1.2: 2024-11-06
    Changes: Data collection, Database references, Structure summary
