6VK7 | pdb_00006vk7

Crystal Structure of reduced Methylosinus trichosporium OB3b Soluble Methane Monooxygenase Hydroxylase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free:
    0.203 (Depositor), 0.204 (DCC)
  • R-Value Work:
    0.162 (Depositor)
  • R-Value Observed:
    0.164 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural Studies of theMethylosinus trichosporiumOB3b Soluble Methane Monooxygenase Hydroxylase and Regulatory Component Complex Reveal a Transient Substrate Tunnel.

Jones, J.C.Banerjee, R.Shi, K.Aihara, H.Lipscomb, J.D.

(2020) Biochemistry 59: 2946-2961

  • DOI: https://doi.org/10.1021/acs.biochem.0c00459
  • Primary Citation Related Structures:
    6VK4, 6VK5, 6VK6, 6VK7, 6VK8

  • PubMed Abstract:

    The metalloenzyme soluble methane monooxygenase (sMMO) consists of hydroxylase (sMMOH), regulatory (MMOB), and reductase components. When sMMOH forms a complex with MMOB, the rate constants are greatly increased for the sequential access of O 2 , protons, and CH 4 to an oxygen-bridged diferrous metal cluster located in the buried active site. Here, we report high-resolution X-ray crystal structures of the diferric and diferrous states of both sMMOH and the sMMOH:MMOB complex using the components from Methylosinus trichosporium OB3b. These structures are analyzed for O 2 access routes enhanced when the complex forms. Previously reported, lower-resolution structures of the sMMOH:MMOB complex from the sMMO of Methylococcus capsulatus Bath revealed a series of cavities through sMMOH postulated to serve as the O 2 conduit. This potential role is evaluated in greater detail using the current structures. Additionally, a search for other potential O 2 conduits in the M. trichosporium OB3b sMMOH:MMOB complex revealed a narrow molecular tunnel, termed the W308-tunnel. This tunnel is sized appropriately for O 2 and traverses the sMMOH-MMOB interface before accessing the active site. The kinetics of reaction of O 2 with the diferrous sMMOH:MMOB complex in solution show that use of the MMOB V41R variant decreases the rate constant for O 2 binding >25000-fold without altering the component affinity. The location of Val41 near the entrance to the W308-tunnel is consistent with the tunnel serving as the primary route for the transfer of O 2 into the active site. Accordingly, the crystal structures show that formation of the diferrous sMMOH:MMOB complex restricts access through the chain of cavities while opening the W308-tunnel.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Methane monooxygenase component A alpha chain526Methylosinus trichosporium OB3bMutation(s): 0
EC: 1.14.13.25
UniProt
Find proteins for P27353 (Methylosinus trichosporium)
Explore P27353
Go to UniProtKB:  P27353
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP27353
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Methane monooxygenase395Methylosinus trichosporium OB3bMutation(s): 0
UniProt
Find proteins for A0A2D2D5X7 (Methylosinus trichosporium (strain ATCC 35070 / NCIMB 11131 / UNIQEM 75 / OB3b))
Explore A0A2D2D5X7
Go to UniProtKB:  A0A2D2D5X7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2D2D5X7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Methane monooxygenase169Methylosinus trichosporium OB3bMutation(s): 0
UniProt
Find proteins for A0A2D2D0T0 (Methylosinus trichosporium (strain ATCC 35070 / NCIMB 11131 / UNIQEM 75 / OB3b))
Explore A0A2D2D0T0
Go to UniProtKB:  A0A2D2D0T0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2D2D0T0
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free:  0.203 (Depositor), 0.204 (DCC)
  • R-Value Work:  0.162 (Depositor)
  • R-Value Observed: 0.164 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.458α = 90
b = 290.452β = 90
c = 139.22γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
PHENIXphasing
PHENIXdata processing
PHENIXdata scaling

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM118030, GM08347
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM118000, GM118047

Revision History  (Full details and data files)

  • Version 1.0: 2020-08-05
    Type: Initial release
  • Version 1.1: 2020-08-26
    Changes: Database references
  • Version 1.2: 2020-09-02
    Changes: Database references
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
