6VF5

DNA Polymerase Mu, 8-oxorGTP:At Product State Ternary Complex, 50 mM Mn2+ (120 min)

PDB DOI: https://doi.org/10.2210/pdb6VF5/pdb
NAKB: 6VF5

Classification: REPLICATION
Organism(s): Homo sapiens, synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2020-01-03 Released: 2021-09-01
Deposition Author(s): Jamsen, J.A., Wilson, S.H.
Funding Organization(s): National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS), Japan Society for the Promotion of Science (JSPS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.191
R-Value Work: 0.165
R-Value Observed: 0.166

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Currently 6VF5 does not have a validation slider image.

This is version 1.2 of the entry. See complete history.

Literature

DNA Polymerase Mu, 8-oxorGTP:At Product State Ternary Complex, 50 mM Mn2+ (120 min)

Jamsen, J.A., Sassa, A., Shock, D.D., Beard, W.A., Wilson, S.H.

To be published.

Macromolecule Content

Total Structure Weight: 46.65 kDa
Atom Count: 3,431
Modelled Residue Count: 345
Deposited Residue Count: 374
Unique protein chains: 1
Unique nucleic acid chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA-directed DNA/RNA polymerase mu	A	356	Homo sapiens	Mutation(s): 0 Gene Names: POLM, polmu EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NP87 (Homo sapiens) Explore Q9NP87 Go to UniProtKB: Q9NP87
PHAROS: Q9NP87 GTEx: ENSG00000122678
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9NP87
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(CPGPGPCPAPTPAPCP*G)-3')	B [auth T]	9	synthetic construct
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Length	Organism	Image
DNA (5'-D(CPGPTPAP*(8GM))-3')	C [auth P]	5	synthetic construct
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 4
Molecule	Chains	Length	Organism	Image
DNA (5'-D(PGPCPCPG)-3')	D	4	synthetic construct
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EPE Query on EPE Download Ideal Coordinates CCD File SDF format, chain M [auth A] MOL2 format, chain M [auth A] mmCIF format, chain M [auth A]	M [auth A]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain M [auth A]
DTT Query on DTT Download Ideal Coordinates CCD File SDF format, chain L [auth A] MOL2 format, chain L [auth A] mmCIF format, chain L [auth A]	L [auth A]	2,3-DIHYDROXY-1,4-DITHIOBUTANE C₄ H₁₀ O₂ S₂ VHJLVAABSRFDPM-IMJSIDKUSA-N		Interactions Focus chain L [auth A]
OXL (Subject of Investigation/LOI) Query on OXL Download Ideal Coordinates CCD File SDF format, chain Q [auth A] MOL2 format, chain Q [auth A] mmCIF format, chain Q [auth A]	Q [auth A]	OXALATE ION C₂ O₄ MUBZPKHOEPUJKR-UHFFFAOYSA-L		Interactions Focus chain Q [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A]	N [auth A], O [auth A], P [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]
MN (Subject of Investigation/LOI) Query on MN Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain R [auth T] SDF format, chain S [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain R [auth T] MOL2 format, chain S [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain R [auth T] mmCIF format, chain S [auth D]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth A] E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], R [auth T], S [auth D]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain R [auth T] Focus chain S [auth D]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain K [auth A]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain J [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.191
R-Value Work: 0.165
R-Value Observed: 0.166
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.982	α = 90
b = 68.718	β = 90
c = 110.413	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
PHENIX	phasing

Structure Validation

View Full Validation Report

Currently 6VF5 does not have a validation slider image.

Entry History & Funding Information

Deposition Data

Released Date: 2021-09-01

Deposition Author(s):

Jamsen, J.A.

Wilson, S.H.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)	United States	Z01-ES050158
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)	United States	Z01-10ES050161
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)	United States	1K99ES029572-01
Japan Society for the Promotion of Science (JSPS)	Japan	16K16195
