6VCE | pdb_00006vce

HIV-1 wild type protease with GRL-026-18A, a crown-like tetrahydropyranotetrahydrofuran with a bridged methylene group as a P2 ligand


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.18 Å
  • R-Value Free:
    0.155 (Depositor), 0.164 (DCC)
  • R-Value Work:
    0.136 (Depositor), 0.145 (DCC)
  • R-Value Observed:
    0.137 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6VCE

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Design, Synthesis, and X-ray Studies of Potent HIV-1 Protease Inhibitors with P2-Carboxamide Functionalities.

Ghosh, A.K.Grillo, A.Raghavaiah, J.Kovela, S.Johnson, M.E.Kneller, D.W.Wang, Y.F.Hattori, S.I.Higashi-Kuwata, N.Weber, I.T.Mitsuya, H.

(2020) ACS Med Chem Lett 11: 1965-1972

  • DOI: https://doi.org/10.1021/acsmedchemlett.9b00670
  • Primary Citation Related Structures:
    6VCE

  • PubMed Abstract:

    The design, synthesis, biological evaluation, and X-ray structural studies are reported for a series of highly potent HIV-1 protease inhibitors. The inhibitors incorporated stereochemically defined amide-based bicyclic and tricyclic ether derivatives as the P2 ligands with ( R )-hydroxyethylaminesulfonamide transition-state isosteres. A number of inhibitors showed excellent HIV-1 protease inhibitory and antiviral activity; however, ligand combination is critical for potency. Inhibitor 4h with a difluorophenylmethyl as the P1 ligand, crown-THF-derived acetamide as the P2 ligand, and a cyclopropylaminobenzothiazole P2'-ligand displayed very potent antiviral activity and maintained excellent antiviral activity against selected multidrug-resistant HIV-1 variants. A high resolution X-ray structure of inhibitor 4h -bound HIV-1 protease provided molecular insight into the binding properties of the new inhibitor.


  • Organizational Affiliation
    • Department of Chemistry and Department of Medicinal Chemistry, Purdue University, West Lafayette, Indiana 47907, United States.

Macromolecule Content

  • Total Structure Weight: 22.61 kDa
  • Atom Count: 2,049
  • Modeled Residue Count: 198
  • Deposited Residue Count: 198
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Protease
A, B
99Human immunodeficiency virus 1Mutation(s): 5
Gene Names: pol
UniProt
Find proteins for P03367 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI))
Explore P03367
Go to UniProtKB:  P03367
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03367
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
G6R
(Subject of Investigation/LOI)

Query on G6R



Download:Ideal Coordinates CCD File
G [auth B]N-[(2S,3R)-4-[{[2-(cyclopropylamino)-1,3-benzothiazol-6-yl]sulfonyl}(2-methylpropyl)amino]-1-(3,5-difluorophenyl)-3-hydroxybutan-2-yl]-2-[(3S,3aR,5S,7aS,8S)-hexahydro-4H-3,5-methanofuro[2,3-b]pyran-8-yl]acetamide
C34 H42 F2 N4 O6 S2
BDFWTUGFCVLPRW-KVUOCWAWSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
K [auth B],
L [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
H [auth B]
I [auth B]
D [auth A],
E [auth A],
F [auth A],
H [auth B],
I [auth B],
J [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
C [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.18 Å
  • R-Value Free:  0.155 (Depositor), 0.164 (DCC)
  • R-Value Work:  0.136 (Depositor), 0.145 (DCC)
  • R-Value Observed: 0.137 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.904α = 90
b = 86.207β = 90
c = 46.09γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesAI150466
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesAI150461
Japan Agency for Medical Research and Development (AMED)JapanJP15fk0410001
Japan Agency for Medical Research and Development (AMED)JapanJP16fk0410101
Other governmentUnited States--
Other governmentJapan--
Other governmentJapan--
Other governmentJapan--

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-01
    Type: Initial release
  • Version 1.1: 2020-11-04
    Changes: Database references, Derived calculations
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
