6VBO | pdb_00006vbo

Crystal structure of anti-HIV-1 antibody DH813 bound to gp120 V2 peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:
    0.208 (Depositor), 0.211 (DCC)
  • R-Value Work:
    0.175 (Depositor), 0.177 (DCC)
  • R-Value Observed:
    0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6VBO

This is version 1.2 of the entry. See complete history

Literature

HIV vaccine delayed boosting increases Env variable region 2-specific antibody effector functions.

Easterhoff, D.Pollara, J.Luo, K.Janus, B.Gohain, N.Williams, L.D.Tay, M.Z.Monroe, A.Peachman, K.Choe, M.Min, S.Lusso, P.Zhang, P.Go, E.P.Desaire, H.Bonsignori, M.Hwang, K.K.Beck, C.Kakalis, M.O'Connell, R.J.Vasan, S.Kim, J.H.Michael, N.L.Excler, J.L.Robb, M.L.Rerks-Ngarm, S.Kaewkungwal, J.Pitisuttithum, P.Nitayaphan, S.Sinangil, F.Tartaglia, J.Phogat, S.Wiehe, K.Saunders, K.O.Montefiori, D.C.Tomaras, G.D.Moody, M.A.Arthos, J.Rao, M.Joyce, M.G.Ofek, G.A.Ferrari, G.Haynes, B.F.

(2020) JCI Insight 5

  • DOI: https://doi.org/10.1172/jci.insight.131437
  • Primary Citation Related Structures:
    6VBO, 6VBP, 6VBQ

  • PubMed Abstract:

    In the RV144 HIV-1 phase III trial, vaccine efficacy directly correlated with the magnitude of the variable region 2-specific (V2-specific) IgG antibody response, and in the presence of low plasma IgA levels, with the magnitude of plasma antibody-dependent cellular cytotoxicity. Reenrollment of RV144 vaccinees in the RV305 trial offered the opportunity to define the function, maturation, and persistence of vaccine-induced V2-specific and other mAb responses after boosting. We show that the RV144 vaccine regimen induced persistent V2 and other HIV-1 envelope-specific memory B cell clonal lineages that could be identified throughout the approximately 11-year vaccination period. Subsequent boosts increased somatic hypermutation, a critical requirement for antibody affinity maturation. Characterization of 22 vaccine-induced V2-specific mAbs with epitope specificities distinct from previously characterized RV144 V2-specific mAbs CH58 and CH59 found increased in vitro antibody-mediated effector functions. Thus, when inducing non-neutralizing antibodies, one method by which to improve HIV-1 vaccine efficacy may be through late boosting to diversify the V2-specific response to increase the breadth of antibody-mediated anti-HIV-1 effector functions.


  • Organizational Affiliation
    • Duke Human Vaccine Institute, Duke University, Durham, North Carolina, USA.

Macromolecule Content

  • Total Structure Weight: 50.13 kDa
  • Atom Count: 3,915
  • Modeled Residue Count: 444
  • Deposited Residue Count: 461
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DH813 light chainA [auth L]218Homo sapiensMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DH813 heavy chainB [auth H]221Homo sapiensMutation(s): 0
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Envelope glycoprotein gp16022Human immunodeficiency virus 1Mutation(s): 0
UniProt
Find proteins for I2E6B7 (Human immunodeficiency virus type 1)
Explore I2E6B7
Go to UniProtKB:  I2E6B7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupI2E6B7
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:  0.208 (Depositor), 0.211 (DCC)
  • R-Value Work:  0.175 (Depositor), 0.177 (DCC)
  • R-Value Observed: 0.176 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.57α = 90
b = 63.92β = 92.96
c = 70.58γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-12
    Type: Initial release
  • Version 1.1: 2023-10-11
    Changes: Data collection, Database references, Refinement description
  • Version 1.2: 2024-10-16
    Changes: Structure summary
