6V3Q | pdb_00006v3q

Crystal Structure of the Metallo-beta-Lactamase FIM-1 from Pseudomonas aeruginosa in the Mono-Zinc Form

• PDB DOI: https://doi.org/10.2210/pdb6V3Q/pdb

• Classification: HYDROLASE
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2019-11-26 Released: 2020-01-15
• Deposition Author(s): Kim, Y., Hatzos-Skintges, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.185 (Depositor), 0.188 (DCC)
• R-Value Work:
  0.165 (Depositor), 0.168 (DCC)
• R-Value Observed:
  0.166 (Depositor)

Starting Model: other

Literature

Crystal Structure of the Metallo-beta-Lactamase FIM-1 from Pseudomonas aeruginosa in the Mono-Zinc Form

Kim, Y., Hatzos-Skintges, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 50.05 kDa
• Atom Count: 3,546
• Modeled Residue Count: 452
• Deposited Residue Count: 460
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Metallo-beta-lactamase FIM-1	A, B	230	Pseudomonas aeruginosa	Mutation(s): 0  Gene Names: blaFIM-1 EC: 3.5.2.6
UniProt
Find proteins for K7SA42 (Pseudomonas aeruginosa) Explore K7SA42  Go to UniProtKB:  K7SA42

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	C [auth A], D [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
IPA	E [auth B]	ISOPROPYL ALCOHOL C3 H8 O KFZMGEQAYNKOFK-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
OCS	A, B	L-PEPTIDE LINKING	C3 H7 N O5 S		CYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.185 (Depositor), 0.188 (DCC)
• R-Value Work:  0.165 (Depositor), 0.168 (DCC)
• R-Value Observed: 0.166 (Depositor)

Space Group: P 3₂

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 128.109	α = 90
b = 128.109	β = 90
c = 41.42	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
MOLREP	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2020-01-15
Deposition Author(s): Kim, Y., Hatzos-Skintges, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History

• Version 1.0: 2020-01-15
  Type: Initial release

• Version 1.1: 2024-04-03
  Changes: Data collection, Database references, Derived calculations, Refinement description
