6UVT | pdb_00006uvt

Human Connexin-26 (Low pH closed conformation)

PDB DOI: https://doi.org/10.2210/pdb6UVT/pdb
EM Map EMD-20916: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): Yes
Membrane Protein: Yes PDBTM

Deposited: 2019-11-04 Released: 2020-04-29
Deposition Author(s): Khan, A.K., Jagielnicki, M., Purdy, M.D., Yeager, M.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 7.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6UVT

This is version 1.1 of the entry. See complete history.

Literature

A Steric 'Ball-and-Chain' Mechanism for pH-Mediated Regulation of Gap Junction Channels

Khan, A.K., Jagielnicki, M., McIntire, W.E., Purdy, M.D., Dharmarajan, V., Griffin, P.R., Yeager, M.

(2020) Cell Rep 31: 1-11

DOI: https://doi.org/10.1016/j.celrep.2020.03.046

Macromolecule Content

Total Structure Weight: 314.58 kDa
Atom Count: 8,448
Modeled Residue Count: 2,112
Deposited Residue Count: 2,712
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Gap junction beta-2 protein	A B [auth K] C [auth L] D [auth B] E [auth H] A, B [auth K], C [auth L], D [auth B], E [auth H], F [auth C], G [auth I], H [auth D], I [auth J], J [auth E], K [auth F], L [auth G]	226	Homo sapiens	Mutation(s): 2 Gene Names: GJB2 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P29033 (Homo sapiens) Explore P29033 Go to UniProtKB: P29033
PHAROS: P29033 GTEx: ENSG00000165474
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P29033
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 7.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX
MODEL REFINEMENT	Coot
RECONSTRUCTION	RELION

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-04-29

Deposition Author(s):

Jagielnicki, M.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R01 HL48908
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)	United States	F30 HL129702-01

Revision History (Full details and data files)

Version 1.0: 2020-04-29
Type: Initial release
Version 1.1: 2024-03-06
Changes: Data collection, Database references
