6UP0

Structure of the Mango-III fluorescent aptamer bound to YO3-Biotin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.178

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6UP0 does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Fluorogenic aptamers resolve the flexibility of RNA junctions using orientation-dependent FRET.

Jeng, S.C.Y.Trachman III, R.J.Weissenboeck, F.Truong, L.Link, K.A.Jepsen, M.D.E.Knutson, J.R.Andersen, E.S.Ferre-D'Amare, A.R.Unrau, P.J.

(2021) RNA 27: 433-444

  • DOI: https://doi.org/10.1261/rna.078220.120
  • Primary Citation of Related Structures:
    6UP0, 7L0Z

  • PubMed Abstract:

    To further understand the transcriptome, new tools capable of measuring folding, interactions, and localization of RNA are needed. Although Förster resonance energy transfer (FRET) is an angle- and distance-dependent phenomenon, the majority of FRET measurements have been used to report distances, by assuming rotationally averaged donor-acceptor pairs. Angle-dependent FRET measurements have proven challenging for nucleic acids due to the difficulties in incorporating fluorophores rigidly into local substructures in a biocompatible manner. Fluorescence turn-on RNA aptamers are genetically encodable tags that appear to rigidly confine their cognate fluorophores, and thus have the potential to report angular-resolved FRET. Here, we use the fluorescent aptamers Broccoli and Mango-III as donor and acceptor, respectively, to measure the angular dependence of FRET. Joining the two fluorescent aptamers by a helix of variable length allowed systematic rotation of the acceptor fluorophore relative to the donor. FRET oscillated in a sinusoidal manner as a function of helix length, consistent with simulated data generated from models of oriented fluorophores separated by an inflexible helix. Analysis of the orientation dependence of FRET allowed us to demonstrate structural rigidification of the NiCo riboswitch upon transition metal-ion binding. This application of fluorescence turn-on aptamers opens the way to improved structural interpretation of ensemble and single-molecule FRET measurements of RNA.


  • Organizational Affiliation

    Department of Molecular Biology and Biochemistry, Simon Fraser University, Burnaby, British Columbia, Canada V5A 1S6.


Macromolecules
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
Mango-III fluorescent aptamerA [auth C],
B [auth D]
38synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YO3 (Subject of Investigation/LOI)
Query on YO3

Download Ideal Coordinates CCD File
F [auth C],
K [auth D]
YO3-biotin
C21 H19 N2 O
VHMUTYCKXYROKA-UHFFFAOYSA-N
K
Query on K

Download Ideal Coordinates CCD File
G [auth C],
L [auth D]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
C
D [auth C]
E [auth C]
H [auth D]
I [auth D]
C,
D [auth C],
E [auth C],
H [auth D],
I [auth D],
J [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.178
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.284α = 90
b = 66.921β = 90
c = 76.628γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report

Currently 6UP0 does not have a validation slider image.



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-21
    Type: Initial release
  • Version 1.1: 2021-05-26
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
