6UOR

MicroED structure of OsPYL/RCAR5 (24-29) at 3 e-/A^2

PDB DOI: https://doi.org/10.2210/pdb6UOR/pdb

Classification: PROTEIN FIBRIL
Organism(s): Oryza sativa
Mutation(s): No

Deposited: 2019-10-15 Released: 2020-05-13
Deposition Author(s): Gallagher-Jones, M., Richards, L.S., Lee, S., Rodriguez, J.A.
Funding Organization(s): National Science Foundation (NSF, United States), Department of Energy (DOE, United States), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON CRYSTALLOGRAPHY
Resolution: 0.90 Å
R-Value Free: 0.240
R-Value Work: 0.206
R-Value Observed: 0.209

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Atomic structures determined from digitally defined nanocrystalline regions

Gallagher-Jones, M., Bustillo, K.C., Ophus, C., Richards, L.S., Ciston, J., Lee, S., Minor, A.M., Rodriguez, J.A.

(2020) IUCrJ 7: 490-499

DOI: https://doi.org/10.1107/S2052252520004030

Macromolecule Content

Total Structure Weight: 0.46 kDa
Atom Count: 32
Modelled Residue Count: 6
Deposited Residue Count: 6
Unique protein chains: 1

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Abscisic acid receptor PYL5	A	6	Oryza sativa	Mutation(s): 0
UniProt
Find proteins for Q6I5C3 (Oryza sativa subsp. japonica) Explore Q6I5C3 Go to UniProtKB: Q6I5C3
Entity Groups
UniProt Group	Q6I5C3
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON CRYSTALLOGRAPHY
Resolution: 0.90 Å
R-Value Free: 0.240
R-Value Work: 0.206
R-Value Observed: 0.209
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 4.73	α = 90
b = 11.32	β = 90
c = 38.93	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2020-05-13

Deposition Author(s):

Gallagher-Jones, M.

Rodriguez, J.A.

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	DMR-1548924
Department of Energy (DOE, United States)	United States	DE-FC02-02ER63421
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35 GM128867

Revision History (Full details and data files)

Version 1.0: 2020-05-13
Type: Initial release
Version 1.1: 2021-06-30
Changes: Data collection
Version 1.2: 2024-03-13
Changes: Data collection, Database references
