6UJ4

Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction

  • Classification: TRANSCRIPTION
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli K-12
  • Mutation(s): No

  • Deposited: 2019-10-02 Released: 2020-04-15
  • Deposition Author(s): Zhao, B.
  • Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.53 Å
  • R-Value Free: 0.177
  • R-Value Work: 0.154
  • R-Value Observed: 0.155

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Discovery of WD Repeat-Containing Protein 5 (WDR5)-MYC Inhibitors Using Fragment-Based Methods and Structure-Based Design.

Chacon Simon, S.Wang, F.Thomas, L.R.Phan, J.Zhao, B.Olejniczak, E.T.Macdonald, J.D.Shaw, J.G.Schlund, C.Payne, W.Creighton, J.Stauffer, S.R.Waterson, A.G.Tansey, W.P.Fesik, S.W.

(2020) J Med Chem 63: 4315-4333

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c00224
  • Primary Citation of Related Structures:
    6UHY, 6UHZ, 6UIF, 6UIK, 6UJ4, 6UJH, 6UJJ, 6UJL, 6UOZ

  • PubMed Abstract:

    The frequent deregulation of MYC and its elevated expression via multiple mechanisms drives cells to a tumorigenic state. Indeed, MYC is overexpressed in up to ∼50% of human cancers and is considered a highly validated anticancer target. Recently, we discovered that WD repeat-containing protein 5 (WDR5) binds to MYC and is a critical cofactor required for the recruitment of MYC to its target genes and reported the first small molecule inhibitors of the WDR5-MYC interaction using structure-based design. These compounds display high binding affinity, but have poor physicochemical properties and are hence not suitable for in vivo studies. Herein, we conducted an NMR-based fragment screening to identify additional chemical matter and, using a structure-based approach, we merged a fragment hit with the previously reported sulfonamide series. Compounds in this series can disrupt the WDR5-MYC interaction in cells, and as a consequence, we observed a reduction of MYC localization to chromatin.


  • Organizational Affiliation

    Department of Chemistry, Vanderbilt University, Nashville, Tennessee 37232, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
WD repeat domain 5
A, B
304Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P61964 (Homo sapiens)
Explore P61964
Go to UniProtKB:  P61964
PHAROS:  P61964
GTEx:  ENSG00000196363
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61964
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Q8S (Subject of Investigation/LOI)
Query on Q8S

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
5-bromo-3-chloro-N-(1-cyclopentyl-2-methyl-1H-imidazol-4-yl)-2-hydroxybenzene-1-sulfonamide
C15 H17 Br Cl N3 O3 S
WOKCPJTYIUMFPY-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
Q8S BindingDB:  6UJ4 Kd: 170 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.53 Å
  • R-Value Free: 0.177
  • R-Value Work: 0.154
  • R-Value Observed: 0.155
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.674α = 90
b = 96.527β = 90
c = 64.944γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data

  • Released Date: 2020-04-15
  • Deposition Author(s): Zhao, B.

Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-15
    Type: Initial release
  • Version 1.1: 2020-05-06
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
