6TBM

Structure of SAGA bound to TBP, including Spt8 and DUB


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 20.0 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of SAGA and mechanism of TBP deposition on gene promoters.

Papai, G.Frechard, A.Kolesnikova, O.Crucifix, C.Schultz, P.Ben-Shem, A.

(2020) Nature 577: 711-716

  • DOI: https://doi.org/10.1038/s41586-020-1944-2
  • Primary Citation of Related Structures:
    6TB4, 6TBM

  • PubMed Abstract:

    SAGA (Spt-Ada-Gcn5-acetyltransferase) is a 19-subunit complex that stimulates transcription via two chromatin-modifying enzymatic modules and by delivering the TATA box binding protein (TBP) to nucleate the pre-initiation complex on DNA, a pivotal event in the expression of protein-encoding genes 1 . Here we present the structure of yeast SAGA with bound TBP. The core of the complex is resolved at 3.5 Å resolution (0.143 Fourier shell correlation). The structure reveals the intricate network of interactions that coordinate the different functional domains of SAGA and resolves an octamer of histone-fold domains at the core of SAGA. This deformed octamer deviates considerably from the symmetrical analogue in the nucleosome and is precisely tuned to establish a peripheral site for TBP, where steric hindrance represses binding of spurious DNA. Complementary biochemical analysis points to a mechanism for TBP delivery and release from SAGA that requires transcription factor IIA and whose efficiency correlates with the affinity of DNA to TBP. We provide the foundations for understanding the specific delivery of TBP to gene promoters and the multiple roles of SAGA in regulating gene expression.


  • Organizational Affiliation

    Institut de Génétique et de Biologie Moléculaire et Cellulaire, Integrated Structural Biology Department, Equipe labellisée Ligue Contre le Cancer, Illkirch, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
TATA-box Binding Protein (TBP)A [auth M]240Komagataella phaffii GS115Mutation(s): 0
Gene Names: SPT15
UniProt
Find proteins for P13393 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P13393
Go to UniProtKB:  P13393
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13393
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Transcriptional coactivator HFI1/ADA1B [auth A]448Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QZA3 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZA3
Go to UniProtKB:  C4QZA3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZA3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit of SAGA histone acetyltransferase complex698Komagataella phaffii GS115Mutation(s): 0
Gene Names: PAS_chr1-4_0651
UniProt
Find proteins for C4QZ39 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZ39
Go to UniProtKB:  C4QZ39
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZ39
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Spt20D [auth F]517Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QZ05 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZ05
Go to UniProtKB:  C4QZ05
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZ05
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit of the SAGA and SAGA-like transcriptional regulatory complexes, interacts with Spt15p to actE [auth D]341Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R3E4 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R3E4
Go to UniProtKB:  C4R3E4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R3E4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit of the SAGA transcriptional regulatory complex, involved in proper assembly of the complexF [auth E]1,191Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R5C7 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R5C7
Go to UniProtKB:  C4R5C7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R5C7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 10G [auth J]217Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QXP2 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QXP2
Go to UniProtKB:  C4QXP2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QXP2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (61/68 kDa) of TFIID and SAGA complexesH [auth K]609Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R150 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R150
Go to UniProtKB:  C4R150
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R150
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (90 kDa) of TFIID and SAGA complexesI [auth G]722Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R4L4 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R4L4
Go to UniProtKB:  C4R4L4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R4L4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (60 kDa) of TFIID and SAGA complexesJ [auth H]485Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QW33 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QW33
Go to UniProtKB:  C4QW33
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QW33
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (17 kDa) of TFIID and SAGA complexes, involved in RNA polymerase II transcription initiationK [auth I]153Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QZS5 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZS5
Go to UniProtKB:  C4QZS5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZS5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Transcription-associated protein3,825Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QYV4 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QYV4
Go to UniProtKB:  C4QYV4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QYV4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Transcriptional regulator involved in glucose repression of Gal4p-regulated genesM [auth B]722Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R2A4 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R2A4
Go to UniProtKB:  C4R2A4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R2A4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Spt8400Komagataella phaffii GS115Mutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
Polyubiquitin-BO [auth R]76Homo sapiensMutation(s): 0
Gene Names: UBB
UniProt & NIH Common Fund Data Resources
Find proteins for P0CG47 (Homo sapiens)
Explore P0CG47
Go to UniProtKB:  P0CG47
PHAROS:  P0CG47
GTEx:  ENSG00000170315
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CG47
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquitin carboxyl-terminal hydrolaseP [auth Q]502Komagataella phaffii GS115Mutation(s): 0
EC: 3.4.19.12
UniProt
Find proteins for C4QY61 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QY61
Go to UniProtKB:  C4QY61
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QY61
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
SAGA-associated factor 11Q [auth O]123Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R2D9 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R2D9
Go to UniProtKB:  C4R2D9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R2D9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
Transcription and mRNA export factor SUS1R [auth P]96Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R1P1 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R1P1
Go to UniProtKB:  C4R1P1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R1P1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
GLZ
Query on GLZ
O [auth R]L-PEPTIDE LINKINGC2 H5 N OGLY
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 20.0 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
French National Research AgencyFranceANR-15-CE11-0022-01
French National Research AgencyFranceANR-10-LABX-0030-INRT
French National Research AgencyFranceANR-10-IDEX-0002-02

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-12
    Type: Initial release
  • Version 1.1: 2021-06-30
    Changes: Advisory, Database references, Derived calculations, Source and taxonomy, Structure summary
  • Version 1.2: 2024-09-25
    Changes: Data collection, Database references, Source and taxonomy
