6T9P | pdb_00006t9p

Human Butyrylcholinesterase in complex with 2-(N-hydroxyimino)-N-[(1R)-3-{4-[(2-methyl-1H-imidazol-1-yl)methyl]-1H-1,2,3-triazol-1-yl}-1- phenylpropyl]acetamide

PDB DOI: https://doi.org/10.2210/pdb6T9P/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Cricetulus griseus
Mutation(s): Yes

Deposited: 2019-10-28 Released: 2020-07-15
Deposition Author(s): Brazzolotto, X., Sinko, G., Marakovic, N., Knezevic, A.
Funding Organization(s): French Ministry of Armed Forces

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.252 (Depositor), 0.253 (DCC)
R-Value Work:
0.210 (Depositor), 0.208 (DCC)
R-Value Observed:
0.212 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 4.3 of the entry. See complete history.

Literature

Enantioseparation, in vitro testing, and structural characterization of triple-binding reactivators of organophosphate-inhibited cholinesterases.

Marakovic, N., Knezevic, A., Roncevic, I., Brazzolotto, X., Kovarik, Z., Sinko, G.

(2020) Biochem J 477: 2771-2790

PubMed: 32639532 Search on PubMed
DOI: https://doi.org/10.1042/BCJ20200192
Primary Citation Related Structures:
6T9P, 6T9S

PubMed Abstract:
The enantiomers of racemic 2-hydroxyimino-N-(azidophenylpropyl)acetamide-derived triple-binding oxime reactivators were separated, and tested for inhibition and reactivation of acetylcholinesterase (AChE) and butyrylcholinesterase (BChE) inhibited with tabun (GA), cyclosarin (GF), sarin (GB), and VX. Both enzymes showed the greatest affinity toward the methylimidazole derivative (III) of 2-hydroxyimino-N-(azidophenylpropyl)acetamide (I). The crystal structure was determined for the complex of oxime III within human BChE, confirming that all three binding groups interacted with active site residues. In the case of BChE inhibited by GF, oximes I (kr = 207 M-1 min-1) and III (kr = 213 M-1 min-1) showed better reactivation efficiency than the reference oxime 2-PAM. Finally, the key mechanistic steps in the reactivation of GF-inhibited BChE with oxime III were modeled using the PM7R6 method, stressing the importance of proton transfer from Nε of His438 to Oγ of Ser203 for achieving successful reactivation.

Organizational Affiliation

Biochemistry and Organic Analytical Chemistry Unit, Institute for Medical Research and Occupational Health, Ksaverska cesta 2, HR-10 000 Zagreb, Croatia.

Macromolecule Content

Total Structure Weight: 62.33 kDa
Atom Count: 4,438
Modeled Residue Count: 526
Deposited Residue Count: 529
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cholinesterase	A	529	Homo sapiens	Mutation(s): 4 Gene Names: BCHE, CHE1 EC: 3.1.1.8
UniProt & NIH Common Fund Data Resources
Find proteins for P06276 (Homo sapiens) Explore P06276 Go to UniProtKB: P06276
PHAROS: P06276 GTEx: ENSG00000114200
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P06276
Glycosylation
Glycosylation Sites: 6	Glycosylation Focus chain A	Go to GlyGen: P06276-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-L-fucopyranose-(1-6)-2-acetamido-2-deoxy-beta-D-glucopyranose	B, C	2		N-Glycosylation	Interactions Focus chain B Focus chain C Interactions & Density Focus chain B Focus chain C
Glycosylation Resources
GlyTouCan: G86851RC GlyCosmos: G86851RC GlyGen: G86851RC

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[1-deoxy-alpha-D-tagatopyranose-(2-6)]2-acetamido-2-deoxy-beta-D-glucopyranose	D	3		N-Glycosylation	Interactions Focus chain D Interactions & Density Focus chain D
Glycosylation Resources
GlyTouCan: G49757HQ GlyCosmos: G49757HQ GlyGen: G49757HQ

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MXB (Subject of Investigation/LOI) Query on MXB Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	(R,E)-2-(hydroxyimino)-N-(3-(4-((2-methyl-1H-imidazol-1-yl)methyl)-1H-1,2,3-triazol-1-yl)-1-phenylpropyl)acetamide C₁₈ H₂₁ N₇ O₂ ZMAXDRHDDCRKQC-MLHZQLSASA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A], H [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A], J [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.252 (Depositor), 0.253 (DCC)
R-Value Work: 0.210 (Depositor), 0.208 (DCC)
R-Value Observed: 0.212 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 154.14	α = 90
b = 154.14	β = 90
c = 127.52	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-07-15

Deposition Author(s):

Funding Organization	Location	Grant Number
French Ministry of Armed Forces	France	NBC-5-C-4210

Revision History (Full details and data files)

Version 1.0: 2020-07-15
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
Version 3.0: 2020-08-19
Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Structure summary
Version 4.0: 2021-02-24
Type: Coordinate replacement
Reason: Ligand geometry
Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Refinement description, Structure summary
Version 4.1: 2022-12-07
Changes: Data collection, Database references
Version 4.2: 2024-01-31
Changes: Data collection, Refinement description
Version 4.3: 2024-11-20
Changes: Structure summary
