6T6X | pdb_00006t6x

Structure of the Bottromycin epimerase BotH in complex with substrate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.25 Å
  • R-Value Free:
    0.175 (Depositor), 0.212 (DCC)
  • R-Value Work:
    0.166 (Depositor)
  • R-Value Observed:
    0.167 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6T6X

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

The bottromycin epimerase BotH defines a group of atypical alpha / beta-hydrolase-fold enzymes.

Sikandar, A.Franz, L.Adam, S.Santos-Aberturas, J.Horbal, L.Luzhetskyy, A.Truman, A.W.Kalinina, O.V.Koehnke, J.

(2020) Nat Chem Biol 16: 1013-1018

  • DOI: https://doi.org/10.1038/s41589-020-0569-y
  • Primary Citation Related Structures:
    6T6H, 6T6X, 6T6Y, 6T6Z, 6T70

  • PubMed Abstract:

    D-amino acids endow peptides with diverse, desirable properties, but the post-translational and site-specific epimerization of L-amino acids into their D-counterparts is rare and chemically challenging. Bottromycins are ribosomally synthesized and post-translationally modified peptides that have overcome this challenge and feature a D-aspartate (D-Asp), which was proposed to arise spontaneously during biosynthesis. We have identified the highly unusual α/β-hydrolase (ABH) fold enzyme BotH as a peptide epimerase responsible for the post-translational epimerization of L-Asp to D-Asp during bottromycin biosynthesis. The biochemical characterization of BotH combined with the structures of BotH and the BotH-substrate complex allowed us to propose a mechanism for this reaction. Bioinformatic analyses of BotH homologs show that similar ABH enzymes are found in diverse biosynthetic gene clusters. This places BotH as the founding member of a group of atypical ABH enzymes that may be able to epimerize non-Asp stereocenters across different families of secondary metabolites.


  • Organizational Affiliation
    • Workgroup Structural Biology of Biosynthetic Enzymes, Helmholtz Institute for Pharmaceutical Research Saarland (HIPS), Helmholtz Centre for Infection Research (HZI), Saarland University, Saarbrücken, Germany.

Macromolecule Content

  • Total Structure Weight: 33.89 kDa
  • Atom Count: 2,296
  • Modeled Residue Count: 253
  • Deposited Residue Count: 310
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
BotH310Streptomyces sp. BC16019Mutation(s): 0
Gene Names: botH
UniProt
Find proteins for K4MHV9 (Streptomyces sp. BC16019)
Explore K4MHV9
Go to UniProtKB:  K4MHV9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK4MHV9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MQW
(Subject of Investigation/LOI)

Query on MQW



Download:Ideal Coordinates CCD File
B [auth A](4~{R})-2-[(1~{R})-1-[[(2~{S})-2-[[(2~{S})-3-methyl-2-[[(4~{Z},6~{S},9~{S},12~{S})-2,8,11-tris(oxidanylidene)-6,9-di(propan-2-yl)-1,4,7,10-tetrazabicyclo[10.3.0]pentadec-4-en-5-yl]amino]butanoyl]amino]-3-phenyl-propanoyl]amino]-3-oxidanyl-3-oxidanylidene-propyl]-4,5-dihydro-1,3-thiazole-4-carboxylic acid
C38 H54 N8 O9 S
PXXAKUWJCGKVNK-JQXGNVTOSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.25 Å
  • R-Value Free:  0.175 (Depositor), 0.212 (DCC)
  • R-Value Work:  0.166 (Depositor)
  • R-Value Observed: 0.167 (Depositor)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.655α = 90
b = 80.285β = 90
c = 89.337γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanyKO 4116/3-1

Revision History  (Full details and data files)

  • Version 1.0: 2020-07-15
    Type: Initial release
  • Version 1.1: 2020-08-26
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
