6S62 | pdb_00006s62

Crystal structure of 2-methylcitrate dehydratase (PrpD) from Pseudomonas aeruginosa in apo form.

PDB DOI: https://doi.org/10.2210/pdb6S62/pdb

Classification: ISOMERASE
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-07-02 Released: 2020-10-14
Deposition Author(s): Wijaya, A.J., Brear, P., Dolan, S.K., Welch, M.
Funding Organization(s): Biotechnology and Biological Sciences Research Council

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free:
0.260 (Depositor), 0.260 (DCC)
R-Value Work:
0.206 (Depositor), 0.208 (DCC)
R-Value Observed:
0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6S62

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of 2-methylcitrate dehydratase (PrpD) from Pseudomonas aeruginosa in apo form.

Wijaya, A.J., Brear, P., Dolan, S.K., Welch, M.

To be published.

Macromolecule Content

Total Structure Weight: 329.72 kDa
Atom Count: 22,926
Modeled Residue Count: 2,906
Deposited Residue Count: 2,964
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Propionate catabolic protein PrpD	A, B, C, D, E A, B, C, D, E, F	494	Pseudomonas aeruginosa PAO1	Mutation(s): 0 Gene Names: prpD, PA0792 EC: 4.2.1.79
UniProt
Find proteins for Q9I5E6 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9I5E6 Go to UniProtKB: Q9I5E6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9I5E6
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.36 Å
R-Value Free: 0.260 (Depositor), 0.260 (DCC)
R-Value Work: 0.206 (Depositor), 0.208 (DCC)
R-Value Observed: 0.209 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 123.48	α = 90
b = 124.54	β = 116.85
c = 126.85	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
DIALS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-10-14

Deposition Author(s):

Funding Organization	Location	Grant Number
Biotechnology and Biological Sciences Research Council	United Kingdom	BB/M019411/1
Biotechnology and Biological Sciences Research Council	United Kingdom	BB/R005435/1

Revision History (Full details and data files)

Version 1.0: 2020-10-14
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
