6S48 | pdb_00006s48

AvaII RESTRICTION ENDONUCLEASE IN COMPLEX WITH PARTIALLY CLEAVED dsDNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.217 (Depositor), 0.222 (DCC)
  • R-Value Work:
    0.176 (Depositor), 0.183 (DCC)
  • R-Value Observed:
    0.178 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6S48

This is version 1.3 of the entry. See complete history

Literature

Restriction endonucleases that cleave RNA/DNA heteroduplexes bind dsDNA in A-like conformation.

Kisiala, M.Kowalska, M.Pastor, M.Korza, H.J.Czapinska, H.Bochtler, M.

(2020) Nucleic Acids Res 48: 6954-6969

  • DOI: https://doi.org/10.1093/nar/gkaa403
  • Primary Citation Related Structures:
    6S48, 6S58

  • PubMed Abstract:

    Restriction endonucleases naturally target DNA duplexes. Systematic screening has identified a small minority of these enzymes that can also cleave RNA/DNA heteroduplexes and that may therefore be useful as tools for RNA biochemistry. We have chosen AvaII (G↓GWCC, where W stands for A or T) as a representative of this group of restriction endonucleases for detailed characterization. Here, we report crystal structures of AvaII alone, in specific complex with partially cleaved dsDNA, and in scanning complex with an RNA/DNA hybrid. The specific complex reveals a novel form of semi-specific dsDNA readout by a hexa-coordinated metal cation, most likely Ca2+ or Mg2+. Substitutions of residues anchoring this non-catalytic metal ion severely impair DNA binding and cleavage. The dsDNA in the AvaII complex is in the A-like form. This creates space for 2'-OH groups to be accommodated without intra-nucleic acid steric conflicts. PD-(D/E)XK restriction endonucleases of known structure that bind their dsDNA targets in the A-like form cluster into structurally similar groups. Most such enzymes, including some not previously studied in this respect, cleave RNA/DNA heteroduplexes. We conclude that A-form dsDNA binding is a good predictor for RNA/DNA cleavage activity.


  • Organizational Affiliation
    • International Institute of Molecular and Cell Biology, Trojdena 4, 02-109 Warsaw, Poland.

Macromolecule Content

  • Total Structure Weight: 68.45 kDa
  • Atom Count: 5,417
  • Modeled Residue Count: 507
  • Deposited Residue Count: 520
  • Unique protein chains: 1
  • Unique nucleic acid chains: 5

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Type II site-specific deoxyribonuclease
A, B
238Nostoc sp. PCC 7120 = FACHB-418Mutation(s): 0
Gene Names: alr0933
UniProt
Find proteins for A0ACD6B950 (Nostoc sp. (strain PCC 7120 / SAG 25.82 / UTEX 2576))
Explore A0ACD6B950
Go to UniProtKB:  A0ACD6B950
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B950
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*AP*TP*GP*GP*TP*CP*CP*TP*AP*C)-3')11synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*TP*AP*G)-3')
D, H
4synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 4
MoleculeChains LengthOrganismImage
DNA (5'-D(P*GP*AP*CP*CP*AP*TP*C)-3')
E, I
7synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 5
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*AP*TP*G)-3')4synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 6
MoleculeChains LengthOrganismImage
DNA (5'-D(P*GP*TP*CP*CP*TP*AP*C)-3')7synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
1PE

Query on 1PE



Download:Ideal Coordinates CCD File
N [auth B]PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
PGE

Query on PGE



Download:Ideal Coordinates CCD File
O [auth B]TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
SER

Query on SER



Download:Ideal Coordinates CCD File
Q [auth B]SERINE
C3 H7 N O3
MTCFGRXMJLQNBG-REOHCLBHSA-N
BME

Query on BME



Download:Ideal Coordinates CCD File
K [auth A],
P [auth B]
BETA-MERCAPTOETHANOL
C2 H6 O S
DGVVWUTYPXICAM-UHFFFAOYSA-N
CA

Query on CA



Download:Ideal Coordinates CCD File
J [auth A],
L [auth B],
M [auth B],
R [auth C],
S [auth E]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.217 (Depositor), 0.222 (DCC)
  • R-Value Work:  0.176 (Depositor), 0.183 (DCC)
  • R-Value Observed: 0.178 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 37.129α = 90
b = 116.21β = 102.91
c = 56.774γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
BALBESphasing
ARP/wARPmodel building
Cootmodel building

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-05-20
    Type: Initial release
  • Version 1.1: 2020-06-10
    Changes: Database references
  • Version 1.2: 2020-07-15
    Changes: Database references
  • Version 1.3: 2024-01-24
    Changes: Data collection, Database references, Derived calculations, Refinement description
