6RDW

Cryo-EM structure of Polytomella F-ATP synthase, Rotary substate 1F, composite map


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Rotary substates of mitochondrial ATP synthase reveal the basis of flexible F 1 -F o coupling.

Murphy, B.J.Klusch, N.Langer, J.Mills, D.J.Yildiz, O.Kuhlbrandt, W.

(2019) Science 364

  • DOI: https://doi.org/10.1126/science.aaw9128
  • Primary Citation of Related Structures:
    6RD4, 6RD5, 6RD6, 6RD7, 6RD8, 6RD9, 6RDA, 6RDB, 6RDC, 6RDD, 6RDE, 6RDF, 6RDG, 6RDH, 6RDI, 6RDJ, 6RDK, 6RDL, 6RDM, 6RDN, 6RDO, 6RDP, 6RDQ, 6RDR, 6RDS, 6RDT, 6RDU, 6RDV, 6RDW, 6RDX, 6RDY, 6RDZ, 6RE0, 6RE1, 6RE2, 6RE3, 6RE4, 6RE5, 6RE6, 6RE7, 6RE8, 6RE9, 6REA, 6REB, 6REC, 6RED, 6REE, 6REF, 6REP, 6RER

  • PubMed Abstract:

    F 1 F o -adenosine triphosphate (ATP) synthases make the energy of the proton-motive force available for energy-consuming processes in the cell. We determined the single-particle cryo-electron microscopy structure of active dimeric ATP synthase from mitochondria of Polytomella sp. at a resolution of 2.7 to 2.8 angstroms. Separation of 13 well-defined rotary substates by three-dimensional classification provides a detailed picture of the molecular motions that accompany c -ring rotation and result in ATP synthesis. Crucially, the F 1 head rotates along with the central stalk and c -ring rotor for the first ~30° of each 120° primary rotary step to facilitate flexible coupling of the stoichiometrically mismatched F 1 and F o subcomplexes. Flexibility is mediated primarily by the interdomain hinge of the conserved OSCP subunit. A conserved metal ion in the proton access channel may synchronize c -ring protonation with rotation.


  • Organizational Affiliation

    Department of Structural Biology, Max Planck Institute of Biophysics, Frankfurt 60438, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ASA-10: Polytomella F-ATP synthase associated subunit 10A [auth 0]82Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A5H1ZR95 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR95
Go to UniProtKB:  A0A5H1ZR95
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR95
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
ATP synthase associated protein ASA1B [auth 1]618Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for Q85JD5 (Polytomella sp. Pringsheim 198.80)
Explore Q85JD5
Go to UniProtKB:  Q85JD5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ85JD5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
ASA-2: Polytomella F-ATP synthase associated subunit 2C [auth 2]441Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7P6B9 (Polytomella sp. Pringsheim 198.80)
Explore D7P6B9
Go to UniProtKB:  D7P6B9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P6B9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial F1F0 ATP synthase associated 32 kDa proteinD [auth 3]325Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for K0J903 (Polytomella sp. Pringsheim 198.80)
Explore K0J903
Go to UniProtKB:  K0J903
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK0J903
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase associated protein ASA4E [auth 4]294Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7NIZ2 (Polytomella sp. Pringsheim 198.80)
Explore D7NIZ2
Go to UniProtKB:  D7NIZ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7NIZ2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial F1F0 ATP synthase associated 14 kDa proteinF [auth 5]123Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for A0A024FSR7 (Polytomella sp. Pringsheim 198.80)
Explore A0A024FSR7
Go to UniProtKB:  A0A024FSR7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A024FSR7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA6G [auth 6]151Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7P897 (Polytomella sp. Pringsheim 198.80)
Explore D7P897
Go to UniProtKB:  D7P897
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P897
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase associated protein ASA7H [auth 7]190Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D8V7I2 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I2
Go to UniProtKB:  D8V7I2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA8I [auth 8]89Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D8V7I7 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I7
Go to UniProtKB:  D8V7I7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
ASA-9: Polytomella F-ATP synthase associated subunit 9J [auth 9]97Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A5H1ZR73 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR73
Go to UniProtKB:  A0A5H1ZR73
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR73
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit c127Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D7P7X5 (Polytomella sp. Pringsheim 198.80)
Explore D7P7X5
Go to UniProtKB:  D7P7X5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P7X5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit 6U [auth M]327Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for H8PGG3 (Polytomella sp. Pringsheim 198.80)
Explore H8PGG3
Go to UniProtKB:  H8PGG3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupH8PGG3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit OSCPV [auth P]229Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D8V7I1 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I1
Go to UniProtKB:  D8V7I1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
epsilon: Polytomella F-ATP synthase epsilon subunitW [auth Q]74Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for A0A5H1ZR74 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR74
Go to UniProtKB:  A0A5H1ZR74
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR74
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit deltaX [auth R]199Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D7P7X6 (Polytomella sp. Pringsheim 198.80)
Explore D7P7X6
Go to UniProtKB:  D7P7X6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P7X6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
ATP synthase gamma chain, mitochondrialY [auth S]317Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q4LDE7 (Polytomella sp. Pringsheim 198.80)
Explore Q4LDE7
Go to UniProtKB:  Q4LDE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4LDE7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
ATP synthase subunit alphaAA [auth U],
BA [auth V],
Z [auth T]
562Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0ZW40 (Polytomella sp. Pringsheim 198.80)
Explore A0ZW40
Go to UniProtKB:  A0ZW40
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ZW40
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
ATP synthase subunit betaCA [auth X],
DA [auth Y],
EA [auth Z]
574Polytomella sp. Pringsheim 198.80Mutation(s): 0
EC: 7.1.2.2
Membrane Entity: Yes
UniProt
Find proteins for A0ZW41 (Polytomella sp. Pringsheim 198.80)
Explore A0ZW41
Go to UniProtKB:  A0ZW41
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ZW41
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP
Query on ATP

Download Ideal Coordinates CCD File
GA [auth T],
IA [auth U],
KA [auth V]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ADP
Query on ADP

Download Ideal Coordinates CCD File
MA [auth X],
OA [auth Y]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
FA [auth M]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
HA [auth T],
JA [auth U],
LA [auth V],
NA [auth X],
PA [auth Y]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.14
RECONSTRUCTIONRELION3

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Max Planck SocietyGermany--
European Molecular Biology OrganizationGermanyALTF 702 2016

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-03
    Type: Initial release
  • Version 1.1: 2019-12-18
    Changes: Data collection, Data processing, Other
  • Version 1.2: 2020-09-30
    Changes: Database references, Derived calculations
  • Version 1.3: 2024-05-22
    Changes: Data collection, Database references
