6PTA | pdb_00006pta

Crystal structure of the ARF family small GTPase ARF1 from Candida albicans in complex with GDP

• PDB DOI: https://doi.org/10.2210/pdb6PTA/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Candida albicans SC5314
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2019-07-15 Released: 2019-07-24
• Deposition Author(s): Stogios, P.J., Evdokimova, E., Di Leo, R., Savchenko, A., Joachimiak, A., Satchell, K.J.F., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:
  0.295 (Depositor)
• R-Value Work:
  0.257 (Depositor)
• R-Value Observed:
  0.259 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the ARF family small GTPase ARF1 from Candida albicans in complex with GDP

Stogios, P.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 82.89 kDa
• Atom Count: 5,447
• Modeled Residue Count: 658
• Deposited Residue Count: 716
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ADP-ribosylation factor	A, B, C, D	179	Candida albicans SC5314	Mutation(s): 0  Gene Names: ARF1, CAALFM_CR08700CA, CaO19.13805, CaO19.6447
UniProt
Find proteins for P22274 (Candida albicans (strain SC5314 / ATCC MYA-2876)) Explore P22274  Go to UniProtKB:  P22274

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GDP (Subject of Investigation/LOI)	E [auth A], F [auth B], G [auth C], H [auth D]	GUANOSINE-5'-DIPHOSPHATE C10 H15 N5 O11 P2 QGWNDRXFNXRZMB-UUOKFMHZSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:  0.295 (Depositor)
• R-Value Work:  0.257 (Depositor)
• R-Value Observed: 0.259 (Depositor)

Space Group: P 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.801	α = 90
b = 42.285	β = 93.699
c = 90.343	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHENIX	phasing
PHENIX	model building
Coot	model building

Structure Validation

Currently 6PTA does not have a validation slider image.

Entry History & Funding Information

Deposition Data

• Released Date: 2019-07-24
Deposition Author(s): Stogios, P.J., Evdokimova, E., Di Leo, R., Savchenko, A., Joachimiak, A., Satchell, K.J.F., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History

• Version 1.0: 2019-07-24
  Type: Initial release

• Version 1.1: 2019-12-18
  Changes: Author supporting evidence
• Version 1.2: 2023-10-11
  Changes: Data collection, Database references, Refinement description
