6OS0

Structure of synthetic nanobody-stabilized angiotensin II type 1 receptor bound to angiotensin II


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.318
  • R-Value Work: 0.259
  • R-Value Observed: 0.265

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6OS0 does not have a validation slider image.


This is version 1.4 of the entry. See complete history


Literature

Angiotensin and biased analogs induce structurally distinct active conformations within a GPCR.

Wingler, L.M.Skiba, M.A.McMahon, C.Staus, D.P.Kleinhenz, A.L.W.Suomivuori, C.M.Latorraca, N.R.Dror, R.O.Lefkowitz, R.J.Kruse, A.C.

(2020) Science 367: 888-892

  • DOI: https://doi.org/10.1126/science.aay9813
  • Primary Citation of Related Structures:
    6OS0, 6OS1, 6OS2

  • PubMed Abstract:

    Biased agonists of G protein-coupled receptors (GPCRs) preferentially activate a subset of downstream signaling pathways. In this work, we present crystal structures of angiotensin II type 1 receptor (AT1R) (2.7 to 2.9 angstroms) bound to three ligands with divergent bias profiles: the balanced endogenous agonist angiotensin II (AngII) and two strongly β-arrestin-biased analogs. Compared with other ligands, AngII promotes more-substantial rearrangements not only at the bottom of the ligand-binding pocket but also in a key polar network in the receptor core, which forms a sodium-binding site in most GPCRs. Divergences from the family consensus in this region, which appears to act as a biased signaling switch, may predispose the AT1R and certain other GPCRs (such as chemokine receptors) to adopt conformations that are capable of activating β-arrestin but not heterotrimeric G q protein signaling.


  • Organizational Affiliation

    Howard Hughes Medical Institute, Duke University Medical Center, Durham, NC 27710, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Type-1 angiotensin II receptor,Soluble cytochrome b562 BRIL fusion protein425Homo sapiensEscherichia coliMutation(s): 1
Gene Names: AGTR1AGTR1AAGTR1BAT2R1AT2R1BcybC
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P30556 (Homo sapiens)
Explore P30556
Go to UniProtKB:  P30556
PHAROS:  P30556
GTEx:  ENSG00000144891
Find proteins for P0ABE7 (Escherichia coli)
Explore P0ABE7
Go to UniProtKB:  P0ABE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP0ABE7P30556
Glycosylation
Glycosylation Sites: 1Go to GlyGen: P30556-1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Nanobody Nb.AT110i1B [auth D]126synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
AngiotensinogenC [auth B]8Homo sapiensMutation(s): 0
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P01019 (Homo sapiens)
Explore P01019
Go to UniProtKB:  P01019
PHAROS:  P01019
GTEx:  ENSG00000135744
Entity Groups
UniProt GroupP01019
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.318
  • R-Value Work: 0.259
  • R-Value Observed: 0.265
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 135.53α = 90
b = 37.83β = 94.41
c = 111.92γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report

Currently 6OS0 does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)United StatesR01HL16037
National Institutes of Health/Office of the DirectorUnited States5DP5OD021345
Other privateUnited States--
Howard Hughes Medical Institute (HHMI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-19
    Type: Initial release
  • Version 1.1: 2020-03-04
    Changes: Database references
  • Version 1.2: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description, Structure summary
  • Version 1.4: 2024-11-20
    Changes: Structure summary
