6NLX | pdb_00006nlx

Crystal Structure of Glyceraldehyde-3-phosphate Dehydrogenase from Naegleria fowleri with bound NAD

PDB DOI: https://doi.org/10.2210/pdb6NLX/pdb

Classification: OXIDOREDUCTASE
Organism(s): Naegleria fowleri
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2019-01-09 Released: 2019-01-23
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.204 (Depositor), 0.206 (DCC)
R-Value Work:
0.169 (Depositor), 0.170 (DCC)
R-Value Observed:
0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of Glyceraldehyde-3-phosphate Dehydrogenase from Naegleria fowleri with bound NAD

Higgins, T.W., Dranow, D.M., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 153.49 kDa
Atom Count: 11,566
Modeled Residue Count: 1,337
Deposited Residue Count: 1,364
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glyceraldehyde-3-phosphate Dehydrogenase	A, B, C, D	341	Naegleria fowleri	Mutation(s): 0 Gene Names: NF0055660 EC: 1.2.1.12
UniProt
Find proteins for A0A4V8H039 (Naegleria fowleri) Explore A0A4V8H039 Go to UniProtKB: A0A4V8H039
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A4V8H039
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD Query on NAD Download:Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain L [auth C] SDF format, chain R [auth D] MOL2 format, chain H [auth B] MOL2 format, chain L [auth C] MOL2 format, chain R [auth D] mmCIF format, chain H [auth B] mmCIF format, chain L [auth C] mmCIF format, chain R [auth D]	H [auth B], L [auth C], R [auth D]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain H [auth B] Focus chain L [auth C] Focus chain R [auth D] Interactions & Density Focus chain H [auth B] Focus chain L [auth C] Focus chain R [auth D]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth B] SDF format, chain K [auth C] SDF format, chain M [auth C] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain P [auth C] SDF format, chain Q [auth D] SDF format, chain S [auth D] SDF format, chain T [auth D] SDF format, chain J [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth B] MOL2 format, chain K [auth C] MOL2 format, chain M [auth C] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain P [auth C] MOL2 format, chain Q [auth D] MOL2 format, chain S [auth D] MOL2 format, chain T [auth D] MOL2 format, chain J [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth B] mmCIF format, chain K [auth C] mmCIF format, chain M [auth C] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain P [auth C] mmCIF format, chain Q [auth D] mmCIF format, chain S [auth D] mmCIF format, chain T [auth D] mmCIF format, chain J [auth B]	E [auth A] F [auth A] G [auth A] I [auth B] J [auth B] E [auth A], F [auth A], G [auth A], I [auth B], J [auth B], K [auth C], M [auth C], N [auth C], O [auth C], P [auth C], Q [auth D], S [auth D], T [auth D]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth C] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain S [auth D] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth C] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain S [auth D] Focus chain T [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.204 (Depositor), 0.206 (DCC)
R-Value Work: 0.169 (Depositor), 0.170 (DCC)
R-Value Observed: 0.169 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 73.01	α = 90
b = 119.94	β = 90
c = 162.9	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
MoRDa	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-01-23

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2019-01-23
Type: Initial release
Version 1.1: 2023-10-11
Changes: Data collection, Database references, Refinement description
Version 1.2: 2025-10-22
Changes: Structure summary
