6NKO | pdb_00006nko

Crystal structure of ForH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.262 (Depositor), 0.262 (DCC)
  • R-Value Work:
    0.212 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6NKO

This is version 1.3 of the entry. See complete history

Literature

Identification of the Formycin A Biosynthetic Gene Cluster from Streptomyces kaniharaensis Illustrates the Interplay between Biological Pyrazolopyrimidine Formation and de Novo Purine Biosynthesis.

Wang, S.A.Ko, Y.Zeng, J.Geng, Y.Ren, D.Ogasawara, Y.Irani, S.Zhang, Y.Liu, H.W.

(2019) J Am Chem Soc 141: 6127-6131

  • DOI: https://doi.org/10.1021/jacs.9b00241
  • Primary Citation Related Structures:
    6NKO

  • PubMed Abstract:

    Formycin A is a potent purine nucleoside antibiotic with a C-glycosidic linkage between the ribosyl moiety and the pyrazolopyrimidine base. Herein, a cosmid is identified from the Streptomyces kaniharaensis genome library that contains the for gene cluster responsible for the biosynthesis of formycin. Subsequent gene deletion experiments and in vitro characterization of the forBCH gene products established their catalytic functions in formycin biosynthesis. Results also demonstrated that PurH from de novo purine biosynthesis plays a key role in pyrazolopyrimidine formation during biosynthesis of formycin A. The participation of PurH in both pathways represents a good example of how primary and secondary metabolism are interlinked.

Macromolecule Content

  • Total Structure Weight: 92.77 kDa
  • Atom Count: 5,940
  • Modeled Residue Count: 768
  • Deposited Residue Count: 864
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ForH
A, B, C, D
216Streptomyces kaniharaensisMutation(s): 0
UniProt
Find proteins for A0A4V8H038 (Streptomyces kaniharaensis)
Explore A0A4V8H038
Go to UniProtKB:  A0A4V8H038
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A4V8H038
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.262 (Depositor), 0.262 (DCC)
  • R-Value Work:  0.212 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.214 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.218α = 90
b = 111.401β = 90
c = 163.396γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)United States--
Welch FoundationUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-05-01
    Changes: Data collection, Database references
  • Version 1.2: 2019-12-18
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
