6N0I | pdb_00006n0i

2.60 Angstrom Resolution Crystal Structure of Elongation Factor G 2 from Pseudomonas putida.

• PDB DOI: https://doi.org/10.2210/pdb6N0I/pdb

• Classification: TRANSLATION
• Organism(s): Pseudomonas putida KT2440
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2018-11-07 Released: 2018-11-14
• Deposition Author(s): Minasov, G., Shuvalova, L., Wawrzak, Z., Cardona-Correa, A., Anderson, W.F., Satchell, K.J.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:
  0.264 (Depositor), 0.258 (DCC)
• R-Value Work:
  0.223 (Depositor), 0.221 (DCC)
• R-Value Observed:
  0.225 (Depositor)

Starting Model: experimental

Literature

Structural genomics of bacterial drug targets: Application of a high-throughput pipeline to solve 58 protein structures from pathogenic and related bacteria.

Inniss, N.L., Minasov, G., Chang, C., Tan, K., Kim, Y., Maltseva, N., Stogios, P., Filippova, E., Michalska, K., Osipiuk, J., Jaroszewki, L., Godzik, A., Savchenko, A., Joachimiak, A., Anderson, W.F., Satchell, K.J.F.

(2025) Microbiol Resour Announc 14: e0020025-e0020025

• PubMed: 40391899
• DOI: https://doi.org/10.1128/mra.00200-25
• Primary Citation Related Structures:
  5TR3, 5TV2, 5TY0, 5U1O, 5U2G, 5U47, 5UE1, 5UME, 5UMG, 5US8, 5USW, 5USX, 5UTX, 5UU6, 5UWY, 5UX9, 5V0I, 5V36, 5VDN, 5VFB, 5VH6, 5VT3, 5WI5, 5WP0, 6AON, 6AOO, 6AWA, 6AZI, 6B4O, 6B5F, 6B8D, 6BAL, 6BK7, 6BLB, 6BQ9, 6BZ0, 6C8Q, 6CMZ, 6CN1, 6CZP, 6E5Y, 6MUQ, 6N0I, 6N7F, 6NBK, 6NFP, 6NKJ, 6PO4, 6PU9, 6PUA, ... Search all related entries


• PubMed Abstract:


  Antibiotic resistance remains a leading cause of severe infections worldwide. Small changes in protein sequence can impact antibiotic efficacy. Here, we report deposition of 58 X-ray crystal structures of bacterial proteins that are known targets for antibiotics, which expands knowledge of structural variation to support future antibiotic discovery or modifications.

---

Organizational Affiliation:
• Department of Microbiology-Immunology, Northwestern University, Feinberg School of Medicine, Chicago, Illinois, USA.
Center for Structural Biology of Infectious Diseases, Feinberg School of Medicine, Northwestern University, Chicago, Illinois, USA.
Consortium for Advanced Science and Engineering, University of Chicago, Chicago, Illinois, USA.
Structural Biology Center, X-ray Science Division, Argonne National Laboratory, Lemont, Illinois, USA.
Biozone, Department of Chemical Engineering and Applied Chemistry, University of Toronto, Toronto, Ontario, Canada.
Biosciences Division, University of California, Riverside, School of Medicine, Riverside, California, USA.
Department of Microbiology, Immunology, and Infectious Diseases, University of Calgary, Calgary, Alberta, Canada.
Department of Biochemistry and Molecular Genetics, Feinberg School of Medicine, Northwestern University, Chicago, Illinois, USA.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: homology

Macromolecule Content

• Total Structure Weight: 156.7 kDa
• Atom Count: 10,642
• Modeled Residue Count: 1,353
• Deposited Residue Count: 1,412
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Elongation factor G 2	A, B	706	Pseudomonas putida KT2440	Mutation(s): 0  Gene Names: fusB, fusA-2, PP_4111
UniProt
Find proteins for Q88FI4 (Pseudomonas putida (strain ATCC 47054 / DSM 6125 / CFBP 8728 / NCIMB 11950 / KT2440)) Explore Q88FI4  Go to UniProtKB:  Q88FI4

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	E [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4	C [auth A], D [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:  0.264 (Depositor), 0.258 (DCC)
• R-Value Work:  0.223 (Depositor), 0.221 (DCC)
• R-Value Observed: 0.225 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36n0i

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.434	α = 90
b = 79.968	β = 94.21
c = 183.516	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-11-14
Deposition Author(s): Minasov, G., Shuvalova, L., Wawrzak, Z., Cardona-Correa, A., Anderson, W.F., Satchell, K.J.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2018-11-14
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2026-02-11
  Changes: Database references, Structure summary
