6MUQ | pdb_00006muq

1.67 Angstrom Resolution Crystal Structure of Murein-DD-endopeptidase from Yersinia enterocolitica.

• PDB DOI: https://doi.org/10.2210/pdb6MUQ/pdb

• Classification: HYDROLASE
• Organism(s): Yersinia enterocolitica subsp. palearctica Y11
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2018-10-23 Released: 2018-10-31
• Deposition Author(s): Minasov, G., Shuvalova, L., Kiryukhina, O., Anderson, W.F., Satchell, K.J.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.67 Å
• R-Value Free:
  0.204 (Depositor), 0.217 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.182 (DCC)
• R-Value Observed:
  0.171 (Depositor)

Starting Model: experimental

Literature

Structural genomics of bacterial drug targets: Application of a high-throughput pipeline to solve 58 protein structures from pathogenic and related bacteria.

Inniss, N.L., Minasov, G., Chang, C., Tan, K., Kim, Y., Maltseva, N., Stogios, P., Filippova, E., Michalska, K., Osipiuk, J., Jaroszewki, L., Godzik, A., Savchenko, A., Joachimiak, A., Anderson, W.F., Satchell, K.J.F.

(2025) Microbiol Resour Announc 14: e0020025-e0020025

• PubMed: 40391899
• DOI: https://doi.org/10.1128/mra.00200-25
• Primary Citation Related Structures:
  5TR3, 5TV2, 5TY0, 5U1O, 5U2G, 5U47, 5UE1, 5UME, 5UMG, 5US8, 5USW, 5USX, 5UTX, 5UU6, 5UWY, 5UX9, 5V0I, 5V36, 5VDN, 5VFB, 5VH6, 5VT3, 5WI5, 5WP0, 6AON, 6AOO, 6AWA, 6AZI, 6B4O, 6B5F, 6B8D, 6BAL, 6BK7, 6BLB, 6BQ9, 6BZ0, 6C8Q, 6CMZ, 6CN1, 6CZP, 6E5Y, 6MUQ, 6N0I, 6N7F, 6NBK, 6NFP, 6NKJ, 6PO4, 6PU9, 6PUA, ... Search all related entries


• PubMed Abstract:


  Antibiotic resistance remains a leading cause of severe infections worldwide. Small changes in protein sequence can impact antibiotic efficacy. Here, we report deposition of 58 X-ray crystal structures of bacterial proteins that are known targets for antibiotics, which expands knowledge of structural variation to support future antibiotic discovery or modifications.

---

Organizational Affiliation:
• Department of Microbiology-Immunology, Northwestern University, Feinberg School of Medicine, Chicago, Illinois, USA.
Center for Structural Biology of Infectious Diseases, Feinberg School of Medicine, Northwestern University, Chicago, Illinois, USA.
Consortium for Advanced Science and Engineering, University of Chicago, Chicago, Illinois, USA.
Structural Biology Center, X-ray Science Division, Argonne National Laboratory, Lemont, Illinois, USA.
Biozone, Department of Chemical Engineering and Applied Chemistry, University of Toronto, Toronto, Ontario, Canada.
Biosciences Division, University of California, Riverside, School of Medicine, Riverside, California, USA.
Department of Microbiology, Immunology, and Infectious Diseases, University of Calgary, Calgary, Alberta, Canada.
Department of Biochemistry and Molecular Genetics, Feinberg School of Medicine, Northwestern University, Chicago, Illinois, USA.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 31.75 kDa
• Atom Count: 2,353
• Modeled Residue Count: 267
• Deposited Residue Count: 283
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Murein-DD-endopeptidase	A	283	Yersinia enterocolitica subsp. palearctica Y11	Mutation(s): 0  Gene Names: Y11_17941
UniProt
Find proteins for A0A0H3NPR7 (Yersinia enterocolitica subsp. palearctica serotype O:3 (strain DSM 13030 / CIP 106945 / Y11)) Explore A0A0H3NPR7  Go to UniProtKB:  A0A0H3NPR7

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
ACT	B [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.67 Å
• R-Value Free:  0.204 (Depositor), 0.217 (DCC)
• R-Value Work:  0.169 (Depositor), 0.182 (DCC)
• R-Value Observed: 0.171 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36muq

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.201	α = 90
b = 37.858	β = 115.75
c = 59.577	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MoRDa	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-10-31
Deposition Author(s): Minasov, G., Shuvalova, L., Kiryukhina, O., Anderson, W.F., Satchell, K.J.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2018-10-31
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2023-11-15
  Changes: Data collection
• Version 1.3: 2024-11-20
  Changes: Structure summary
• Version 1.4: 2026-02-11
  Changes: Database references
