6LIJ | pdb_00006lij

Crassostrea gigas ferritin

PDB DOI: https://doi.org/10.2210/pdb6LIJ/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Magallana gigas
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-12-11 Released: 2020-12-16
Deposition Author(s): Li, H., Zang, J., Tan, X., Wang, Z., Du, M.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.230 (Depositor), 0.228 (DCC)
R-Value Work:
0.193 (Depositor), 0.193 (DCC)
R-Value Observed:
0.195 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6LIJ

This is version 1.1 of the entry. See complete history.

Literature

Crassostrea gigas ferritin

Li, H., Zang, J., Tan, X., Wang, Z., Du, M.

To be published.

Macromolecule Content

Total Structure Weight: 19.82 kDa
Atom Count: 1,455
Modeled Residue Count: 169
Deposited Residue Count: 169
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ferritin	A	169	Magallana gigas	Mutation(s): 0 Gene Names: fer, CGI_10027591 EC: 1.16.3.1
UniProt
Find proteins for Q70MM3 (Magallana gigas) Explore Q70MM3 Go to UniProtKB: Q70MM3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q70MM3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.230 (Depositor), 0.228 (DCC)
R-Value Work: 0.193 (Depositor), 0.193 (DCC)
R-Value Observed: 0.195 (Depositor)

Space Group: F 4 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 183.007	α = 90
b = 183.007	β = 90
c = 183.007	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2020-12-16

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	31730069

Revision History (Full details and data files)

Version 1.0: 2020-12-16
Type: Initial release
Version 1.1: 2023-11-22
Changes: Data collection, Database references, Refinement description
