6LDL

Crystal structure of CYP116B46-N(20-445) from Tepidiphilus thermophilus in complex with HEME


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.38 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.149
  • R-Value Observed: 0.150

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural insight into the electron transfer pathway of a self-sufficient P450 monooxygenase.

Zhang, L.Xie, Z.Liu, Z.Zhou, S.Ma, L.Liu, W.Huang, J.W.Ko, T.P.Li, X.Hu, Y.Min, J.Yu, X.Guo, R.T.Chen, C.C.

(2020) Nat Commun 11: 2676-2676

  • DOI: https://doi.org/10.1038/s41467-020-16500-5
  • Primary Citation of Related Structures:
    6LAA, 6LDL

  • PubMed Abstract:

    Cytochrome P450 monooxygenases are versatile heme-thiolate enzymes that catalyze a wide range of reactions. Self-sufficient cytochrome P450 enzymes contain the redox partners in a single polypeptide chain. Here, we present the crystal structure of full-length CYP116B46, a self-sufficient P450. The continuous polypeptide chain comprises three functional domains, which align well with the direction of electrons traveling from FMN to the heme through the [2Fe-2S] cluster. FMN and the [2Fe-2S] cluster are positioned closely, which facilitates efficient electron shuttling. The edge-to-edge straight-line distance between the [2Fe-2S] cluster and heme is approx. 25.3 Å. The role of several residues located between the [2Fe-2S] cluster and heme in the catalytic reaction is probed in mutagenesis experiments. These findings not only provide insights into the intramolecular electron transfer of self-sufficient P450s, but are also of interest for biotechnological applications of self-sufficient P450s.


  • Organizational Affiliation

    State Key Laboratory of Biocatalysis and Enzyme Engineering, Hubei Collaborative Innovation Center for Green Transformation of Bio-Resources, Hubei Key Laboratory of Industrial Biotechnology, School of Life Sciences, Hubei University, Wuhan, 430062, P. R. China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome P450426Tepidiphilus thermophilusMutation(s): 0
Gene Names: Ga0061068_103196
UniProt
Find proteins for A0A0K6ITW2 (Tepidiphilus thermophilus)
Explore A0A0K6ITW2
Go to UniProtKB:  A0A0K6ITW2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0K6ITW2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.38 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.149
  • R-Value Observed: 0.150
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.471α = 90
b = 75.511β = 90
c = 105.148γ = 90
Software Package:
Software NamePurpose
HKL-2000data scaling
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-28
    Type: Initial release
  • Version 1.1: 2023-11-22
    Changes: Data collection, Database references, Refinement description
