6KW3

The ClassA RSC-Nucleosome Complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.13 Å
  • Aggregation State: CELL
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of the RSC complex bound to the nucleosome.

Ye, Y.Wu, H.Chen, K.Clapier, C.R.Verma, N.Zhang, W.Deng, H.Cairns, B.R.Gao, N.Chen, Z.

(2019) Science 366: 838-843

  • DOI: https://doi.org/10.1126/science.aay0033
  • Primary Citation of Related Structures:
    6K15, 6KW3, 6KW4

  • PubMed Abstract:

    The RSC complex remodels chromatin structure and regulates gene transcription. We used cryo-electron microscopy to determine the structure of yeast RSC bound to the nucleosome. RSC is delineated into the adenosine triphosphatase motor, the actin-related protein module, and the substrate recruitment module (SRM). RSC binds the nucleosome mainly through the motor, with the auxiliary subunit Sfh1 engaging the H2A-H2B acidic patch to enable nucleosome ejection. SRM is organized into three substrate-binding lobes poised to bind their respective nucleosomal epitopes. The relative orientations of the SRM and the motor on the nucleosome explain the directionality of DNA translocation and promoter nucleosome repositioning by RSC. Our findings shed light on RSC assembly and functionality, and they provide a framework to understand the mammalian homologs BAF/PBAF and the Sfh1 ortholog INI1/BAF47, which are frequently mutated in cancers.


  • Organizational Affiliation

    MOE Key Laboratory of Protein Science, Tsinghua University, Beijing 100084, P.R. China.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4A [auth B],
E [auth R]
103Xenopus laevisMutation(s): 0
UniProt
Find proteins for P62799 (Xenopus laevis)
Explore P62799
Go to UniProtKB:  P62799
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62799
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3.2B [auth N],
D [auth Q]
136Xenopus laevisMutation(s): 0
UniProt
Find proteins for P84233 (Xenopus laevis)
Explore P84233
Go to UniProtKB:  P84233
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP84233
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2AC [auth O],
F [auth S]
130Xenopus laevisMutation(s): 0
Gene Names: hist1h2ajLOC494591XELAEV_18003602mg
UniProt
Find proteins for P06897 (Xenopus laevis)
Explore P06897
Go to UniProtKB:  P06897
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06897
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Nuclear protein STH1/NPS1BA [auth Y],
I [auth W],
S [auth J]
1,359Saccharomyces cerevisiae S288CMutation(s): 0
EC: 3.6.4.12
UniProt
Find proteins for P32597 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32597
Go to UniProtKB:  P32597
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32597
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Actin-related protein 7J [auth f]477Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q12406 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12406
Go to UniProtKB:  Q12406
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12406
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Regulator of Ty1 transposition protein 102K [auth h]157Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for P53330 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53330
Go to UniProtKB:  P53330
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53330
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex subunit RSC7L [auth F]435Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for P32832 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32832
Go to UniProtKB:  P32832
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32832
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex protein RSC8M [auth H],
N [auth D]
557Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for P43609 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P43609
Go to UniProtKB:  P43609
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP43609
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex subunit RSC9O [auth M]581Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q03124 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03124
Go to UniProtKB:  Q03124
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03124
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex protein RSC6P [auth I]483Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for P25632 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25632
Go to UniProtKB:  P25632
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25632
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex subunit SFH1Q [auth G]426Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q06168 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q06168
Go to UniProtKB:  Q06168
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06168
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex protein RSC58R [auth A]502Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q07979 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q07979
Go to UniProtKB:  Q07979
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ07979
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
High temperature lethal protein 1T [auth E]78Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q9URQ5 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q9URQ5
Go to UniProtKB:  Q9URQ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9URQ5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex protein RSC30U [auth C]883Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for P38781 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38781
Go to UniProtKB:  P38781
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38781
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex protein RSC3V [auth K]885Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q06639 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q06639
Go to UniProtKB:  Q06639
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06639
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex subunit RSC4W [auth X]625Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q02206 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q02206
Go to UniProtKB:  Q02206
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ02206
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
Chromatin structure-remodeling complex subunit RSC2X [auth L]889Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q06488 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q06488
Go to UniProtKB:  Q06488
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06488
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4Y [auth T],
Z [auth P]
126Xenopus laevisMutation(s): 0
Gene Names: XELAEV_18028549mg
UniProt
Find proteins for P02281 (Xenopus laevis)
Explore P02281
Go to UniProtKB:  P02281
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02281
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChains Sequence LengthOrganismDetailsImage
Actin-like protein ARP9AA [auth g]467Saccharomyces cerevisiae S288CMutation(s): 0
UniProt
Find proteins for Q05123 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q05123
Go to UniProtKB:  Q05123
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ05123
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
DNA 167G [auth U]167Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains LengthOrganismImage
DNA 167H [auth V]167Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
CA [auth H]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.13 Å
  • Aggregation State: CELL
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-11-13
    Type: Initial release
  • Version 1.1: 2019-11-27
    Changes: Database references
  • Version 1.2: 2024-03-27
    Changes: Data collection, Database references
