6JL7

crystal structure of TBC1D23 N terminal domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.217
  • R-Value Observed: 0.219

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of TBC1D23 N-terminus reveals a novel role for rhodanese domain.

Liu, D.Yang, F.Liu, Z.Wang, J.Huang, W.Meng, W.Billadeau, D.D.Sun, Q.Mo, X.Jia, D.

(2020) PLoS Biol 18: e3000746-e3000746

  • DOI: https://doi.org/10.1371/journal.pbio.3000746
  • Primary Citation of Related Structures:
    6JL7

  • PubMed Abstract:

    Members of the Tre2-Bub2-Cdc16 (TBC) family often function to regulate membrane trafficking and to control signaling transductions pathways. As a member of the TBC family, TBC1D23 is critical for endosome-to-Golgi cargo trafficking by serving as a bridge between Golgi-bound golgin-97/245 and the WASH/FAM21 complex on endosomal vesicles. However, the exact mechanisms by which TBC1D23 regulates cargo transport are poorly understood. Here, we present the crystal structure of the N-terminus of TBC1D23 (D23N), which consists of both the TBC and rhodanese domains. We show that the rhodanese domain is unlikely to be an active sulfurtransferase or phosphatase, despite containing a putative catalytic site. Instead, it packs against the TBC domain and forms part of the platform to interact with golgin-97/245. Using the zebrafish model, we show that impacting golgin-97/245-binding, but not the putative catalytic site, impairs neuronal growth and brain development. Altogether, our studies provide structural and functional insights into an essential protein that is required for organelle-specific trafficking and brain development.


  • Organizational Affiliation

    Department of Pediatric Surgery and Laboratory of Stem Cell Biology, State Key Laboratory of Biotherapy, West China Hospital, Sichuan University, Chengdu, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
TBC1 domain family member 23444Homo sapiensMutation(s): 0
Gene Names: TBC1D23NS4ATP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NUY8 (Homo sapiens)
Explore Q9NUY8
Go to UniProtKB:  Q9NUY8
PHAROS:  Q9NUY8
GTEx:  ENSG00000036054
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NUY8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.217
  • R-Value Observed: 0.219
  • Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 151.736α = 90
b = 151.736β = 90
c = 38.604γ = 120
Software Package:
Software NamePurpose
HKL-2000data scaling
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
AutoSolphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-03-04
    Type: Initial release
  • Version 1.1: 2021-09-15
    Changes: Database references
  • Version 1.2: 2024-11-13
    Changes: Data collection, Structure summary
