6IZX | pdb_00006izx

The RNA-dependent RNA polymerase domain of dengue 2 NS5, bound with RK-0404678


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free:
    0.231 (Depositor), 0.238 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.203 (DCC)
  • R-Value Observed:
    0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6IZX

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Discovery of a small molecule inhibitor targeting dengue virus NS5 RNA-dependent RNA polymerase.

Shimizu, H.Saito, A.Mikuni, J.Nakayama, E.E.Koyama, H.Honma, T.Shirouzu, M.Sekine, S.I.Shioda, T.

(2019) PLoS Negl Trop Dis 13: e0007894-e0007894

  • DOI: https://doi.org/10.1371/journal.pntd.0007894
  • Primary Citation Related Structures:
    6IZX, 6IZY, 6IZZ, 6J00

  • PubMed Abstract:

    Dengue is a mosquito-borne viral infection that has spread globally in recent years. Around half of the world's population, especially in the tropics and subtropics, is at risk of infection. Every year, 50-100 million clinical cases are reported, and more than 500,000 patients develop the symptoms of severe dengue infection: dengue haemorrhagic fever and dengue shock syndrome, which threaten life in Asia and Latin America. No antiviral drug for dengue is available. The dengue virus (DENV) non-structural protein 5 (NS5), which possesses the RNA-dependent RNA polymerase (RdRp) activity and is responsible for viral replication and transcription, is an attractive target for anti-dengue drug development. In the present study, 16,240 small-molecule compounds in a fragment library were screened for their capabilities to inhibit the DENV type 2 (DENV2) RdRp activities in vitro. Based on in cellulo antiviral and cytotoxity assays, we selected the compound RK-0404678 with the EC50 value of 6.0 μM for DENV2. Crystallographic analyses revealed two unique binding sites for RK-0404678 within the RdRp, which are conserved in flavivirus NS5 proteins. No resistant viruses emerged after nine rounds of serial passage of DENV2 in the presence of RK-0404678, suggesting the high genetic barrier of this compound to the emergence of a resistant virus. Collectively, RK-0404678 and its binding sites provide a new framework for antiviral drug development.


  • Organizational Affiliation
    • RIKEN Center for Biosystems Dynamics Research, Suehiro-cho, Tsurumi-ku, Yokohama, Japan.

Macromolecule Content

  • Total Structure Weight: 80.71 kDa
  • Atom Count: 4,975
  • Modeled Residue Count: 581
  • Deposited Residue Count: 686
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Genome polyprotein686dengue virus type 2Mutation(s): 0
UniProt
Find proteins for P14340 (Dengue virus type 2 (strain Thailand/NGS-C/1944))
Explore P14340
Go to UniProtKB:  P14340
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14340
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
B5C
(Subject of Investigation/LOI)

Query on B5C



Download:Ideal Coordinates CCD File
M [auth A],
N [auth A]
2-oxo-2H-1,3-benzoxathiol-5-yl acetate
C9 H6 O4 S
GBLGMSCMLNOGSY-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
B [auth A],
C [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CO

Query on CO



Download:Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
H [auth A]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A]
COBALT (II) ION
Co
XLJKHNWPARRRJB-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free:  0.231 (Depositor), 0.238 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.203 (DCC)
  • R-Value Observed: 0.198 (Depositor)
Space Group: I 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 236.5α = 90
b = 236.5β = 90
c = 236.5γ = 90
Software Package:
Software NamePurpose
xia2data scaling
PHENIXrefinement
Cootmodel building
xia2data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Agency for Medical Research and Development (AMED)Japan--
Japan Society for the Promotion of ScienceJapan17K07322

Revision History  (Full details and data files)

  • Version 1.0: 2019-12-25
    Type: Initial release
  • Version 1.1: 2021-01-13
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
