6IW5 | pdb_00006iw5

Crystal structure of YFV-China sE in prefusion state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.292 (Depositor), 0.292 (DCC)
  • R-Value Work:
    0.236 (Depositor), 0.242 (DCC)
  • R-Value Observed:
    0.239 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6IW5

This is version 1.1 of the entry. See complete history

Literature

Double Lock of a Human Neutralizing and Protective Monoclonal Antibody Targeting the Yellow Fever Virus Envelope.

Lu, X.Xiao, H.Li, S.Pang, X.Song, J.Liu, S.Cheng, H.Li, Y.Wang, X.Huang, C.Guo, T.Ter Meulen, J.Daffis, S.Yan, J.Dai, L.Rao, Z.Klenk, H.D.Qi, J.Shi, Y.Gao, G.F.

(2019) Cell Rep 26: 438-446.e5

  • DOI: https://doi.org/10.1016/j.celrep.2018.12.065
  • Primary Citation Related Structures:
    6IVZ, 6IW0, 6IW1, 6IW2, 6IW4, 6IW5

  • PubMed Abstract:

    Yellow fever virus (YFV), a deadly human pathogen, is the prototype of the genus Flavivirus. Recently, YFV re-emerged in Africa and Brazil, leading to hundreds of deaths, with some cases imported to China. Prophylactic or therapeutic countermeasures are urgently needed. Previously, several human monoclonal antibodies against YFV were screened out by phage display. Here, we find that one of them, 5A, exhibits high neutralizing potency and good protection. Crystallographic analysis of the YFV envelope (E) protein in its pre- and post-fusion states shows conformations similar to those observed in other E proteins of flaviviruses. Furthermore, the structures of 5A in complex with the E protein in both states are resolved, revealing an invariant recognition site. Structural analysis and functional data suggest that 5A has high neutralization potency because it interferes with virus entry by preventing both virus attachment and fusion. These findings will be instrumental for immunogen or inhibitor design.


  • Organizational Affiliation
    • Laboratory of Protein Engineering and Vaccines, Tianjin Institute of Industrial Biotechnology, Chinese Academy of Sciences, Tianjin 300308, China.

Macromolecule Content

  • Total Structure Weight: 171.11 kDa
  • Atom Count: 12,133
  • Modeled Residue Count: 1,572
  • Deposited Residue Count: 1,572
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Envelope protein
A, B, C, D
393Yellow fever virusMutation(s): 0
Gene Names: E
UniProt
Find proteins for Q89292 (Yellow fever virus)
Explore Q89292
Go to UniProtKB:  Q89292
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ89292
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.292 (Depositor), 0.292 (DCC)
  • R-Value Work:  0.236 (Depositor), 0.242 (DCC)
  • R-Value Observed: 0.239 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.785α = 90
b = 121.362β = 93.46
c = 101.581γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-13
    Type: Initial release
  • Version 1.1: 2024-11-13
    Changes: Data collection, Database references, Structure summary
