6IN5 | pdb_00006in5

Crystal structure of H5N2 hemagglutinin G228S Q226L mutant with 3SLN from A/chicken/Taiwan/0502/2012

• PDB DOI: https://doi.org/10.2210/pdb6IN5/pdb

• Classification: VIRAL PROTEIN
• Organism(s): unidentified influenza virus
• Expression System: unidentified baculovirus
• Mutation(s): No


• Deposited: 2018-10-24 Released: 2019-10-30
• Deposition Author(s): Lin, T.H., Lee, M.S., Liu, J.S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.92 Å
• R-Value Free:
  0.291 (Depositor), 0.289 (DCC)
• R-Value Work:
  0.219 (Depositor), 0.219 (DCC)
• R-Value Observed:
  0.223 (Depositor)

Starting Model: experimental

Literature

crystal structure of H5 hemagglutinin from A/chicken/Taiwan/0502/2012

Lin, T.H., Lee, M.S., Wu, W.G., Liu, J.S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 66.82 kDa
• Atom Count: 3,986
• Modeled Residue Count: 495
• Deposited Residue Count: 586
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemagglutinin	A	586	unidentified influenza virus	Mutation(s): 0
UniProt
Find proteins for A0A059VBQ9 (Influenza A virus) Explore A0A059VBQ9  Go to UniProtKB:  A0A059VBQ9

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
N-acetyl-alpha-neuraminic acid-(2-3)-beta-D-galactopyranose	B	2		N/A
Glycosylation Resources
GlyTouCan: G30207PZ GlyCosmos: G30207PZ GlyGen: G30207PZ

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.92 Å
• R-Value Free:  0.291 (Depositor), 0.289 (DCC)
• R-Value Work:  0.219 (Depositor), 0.219 (DCC)
• R-Value Observed: 0.223 (Depositor)

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 110.323	α = 90
b = 110.323	β = 90
c = 314.165	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
Coot	model building
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-10-30
Deposition Author(s): Lin, T.H., Lee, M.S., Liu, J.S.

Revision History

• Version 1.0: 2019-10-30
  Type: Initial release

• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
• Version 2.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
• Version 2.2: 2024-11-13
  Changes: Structure summary
