6I8X | pdb_00006i8x

As-p18, an extracellular fatty acid binding protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.220 (Depositor), 0.224 (DCC)
  • R-Value Work:
    0.179 (Depositor), 0.181 (DCC)
  • R-Value Observed:
    0.181 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6I8X

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

As-p18, an extracellular fatty acid binding protein of nematodes, exhibits unusual structural features.

Ibanez-Shimabukuro, M.Rey-Burusco, M.F.Gabrielsen, M.Franchini, G.R.Riboldi-Tunnicliffe, A.Roe, A.J.Griffiths, K.Cooper, A.Corsico, B.Kennedy, M.W.Smith, B.O.

(2019) Biosci Rep

  • DOI: https://doi.org/10.1042/BSR20191292
  • Primary Citation Related Structures:
    6I8X, 6I9F

  • PubMed Abstract:

    Intracellular lipid-binding proteins (iLBPs) of the fatty acid-binding protein (FABP) family of animals transport, mainly fatty acids or retinoids, are confined to the cytosol and have highly similar 3D structures. In contrast, nematodes possess fatty acid-binding proteins (nemFABPs) that are secreted into the perivitelline fluid surrounding their developing embryos. We report structures of As-p18, a nemFABP of the large intestinal roundworm Ascaris suum , with ligand bound, determined using X-ray crystallography and nuclear magnetic resonance spectroscopy. In common with other FABPs, As-p18 comprises a ten β-strand barrel capped by two short α-helices, with the carboxylate head group of oleate tethered in the interior of the protein. However, As-p18 exhibits two distinctive longer loops amongst β-strands not previously seen in a FABP. One of these is adjacent to the presumed ligand entry portal, so it may help to target the protein for efficient loading or unloading of ligand. The second, larger loop is at the opposite end of the molecule and has no equivalent in any iLBP structure yet determined. As-p18 preferentially binds a single 18-carbon fatty acid ligand in its central cavity but in an orientation that differs from iLBPs. The unusual structural features of nemFABPs may relate to resourcing of developing embryos of nematodes.


  • Organizational Affiliation
    • Instituto de Investigaciones Bioquímicas de La Plata, CONICET-UNLP, Facultad de Ciencias Médicas, calles 60 y 120, 1900-La Plata, Argentina.

Macromolecule Content

  • Total Structure Weight: 36.66 kDa
  • Atom Count: 2,645
  • Modeled Residue Count: 292
  • Deposited Residue Count: 298
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Fatty acid-binding protein homolog
A, B
149Ascaris suumMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P55776 (Ascaris suum)
Explore P55776
Go to UniProtKB:  P55776
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP55776
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
VCA
(Subject of Investigation/LOI)

Query on VCA



Download:Ideal Coordinates CCD File
C [auth A],
M [auth B]
VACCENIC ACID
C18 H34 O2
UWHZIFQPPBDJPM-FPLPWBNLSA-N
TAM

Query on TAM



Download:Ideal Coordinates CCD File
K [auth A],
L [auth A]
TRIS(HYDROXYETHYL)AMINOMETHANE
C7 H17 N O3
GKODZWOPPOTFGA-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
H [auth A]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
N [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.220 (Depositor), 0.224 (DCC)
  • R-Value Work:  0.179 (Depositor), 0.181 (DCC)
  • R-Value Observed: 0.181 (Depositor)
Space Group: I 4
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 102.254α = 90
b = 102.254β = 90
c = 103.392γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom083625
Biotechnology and Biological Sciences Research CouncilUnited KingdomBB/G011389/1

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-17
    Type: Initial release
  • Version 1.1: 2024-01-24
    Changes: Data collection, Database references, Refinement description
