6HR4 | pdb_00006hr4

Apo form of penicillin-binding protein 3 from P. aeruginosa

PDB DOI: https://doi.org/10.2210/pdb6HR4/pdb

Classification: PENICILLIN-BINDING PROTEIN
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2018-09-26 Released: 2019-10-23
Deposition Author(s): Bellini, D., Dowson, C.G.
Funding Organization(s): Medical Research Council (United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free:
0.226 (Depositor), 0.224 (DCC)
R-Value Work:
0.207 (Depositor), 0.207 (DCC)
R-Value Observed:
0.208 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6HR4

This is version 1.1 of the entry. See complete history.

Literature

Apo form of penicillin-binding protein 3 from P. aeruginosa

Bellini, D., Dowson, C.G.

To be published.

Macromolecule Content

Total Structure Weight: 57.87 kDa
Atom Count: 4,492
Modeled Residue Count: 504
Deposited Residue Count: 535
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptidoglycan D,D-transpeptidase FtsI	A	535	Pseudomonas aeruginosa PAO1	Mutation(s): 0 Gene Names: ftsI, pbpB, PA4418 EC: 3.4.16.4
UniProt
Find proteins for G3XD46 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore G3XD46 Go to UniProtKB: G3XD46
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	G3XD46
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.19 Å
R-Value Free: 0.226 (Depositor), 0.224 (DCC)
R-Value Work: 0.207 (Depositor), 0.207 (DCC)
R-Value Observed: 0.208 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.548	α = 90
b = 82.14	β = 90
c = 88.113	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DIALS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2019-10-23

Deposition Author(s):

Funding Organization	Location	Grant Number
Medical Research Council (United Kingdom)	United Kingdom	grant.MR/P007503/1

Revision History (Full details and data files)

Version 1.0: 2019-10-23
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
