6GUV | pdb_00006guv

BTB domain of mouse PATZ1

• PDB DOI: https://doi.org/10.2210/pdb6GUV/pdb

• Classification: TRANSCRIPTION
• Organism(s): Mus musculus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-06-19 Released: 2019-10-09
• Deposition Author(s): Alt, A., Piepoli, S., Erman, B., Mancini, E.J.
• Funding Organization(s): Royal Society

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.29 Å
• R-Value Free:
  0.245 (Depositor), 0.249 (DCC)
• R-Value Work:
  0.209 (Depositor), 0.211 (DCC)
• R-Value Observed:
  0.211 (Depositor)

Starting Model: experimental

Literature

Structural analysis of the PATZ1 BTB domain homodimer

Piepoli, S., Alt, A., Atilgan, C., Mancini, E.J., Erman, B.

(2020) Acta Crystallogr D Biol Crystallogr

• DOI: https://doi.org/10.1107/S2059798320005355

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: SAXS, gel filtration

Macromolecule Content

• Total Structure Weight: 18.79 kDa
• Atom Count: 1,123
• Modeled Residue Count: 134
• Deposited Residue Count: 175
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
POZ (BTB) and AT hook-containing zinc finger 1	A	175	Mus musculus	Mutation(s): 0  Gene Names: Patz1, mazr, Zfp278, mCG_14719
UniProt & NIH Common Fund Data Resources
Find proteins for Q5NBY9 (Mus musculus) Explore Q5NBY9  Go to UniProtKB:  Q5NBY9
IMPC:  MGI:1891832

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.29 Å
• R-Value Free:  0.245 (Depositor), 0.249 (DCC)
• R-Value Work:  0.209 (Depositor), 0.211 (DCC)
• R-Value Observed: 0.211 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 43.232	α = 90
b = 43.232	β = 90
c = 162.946	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2019-10-09
Deposition Author(s): Alt, A., Piepoli, S., Erman, B., Mancini, E.J.

---

Funding Organization	Location	Grant Number
Royal Society	United Kingdom	NI140172

Revision History

• Version 1.0: 2019-10-09
  Type: Initial release

• Version 1.1: 2019-10-16
  Changes: Data collection, Database references, Source and taxonomy, Structure summary
• Version 1.2: 2020-10-21
  Changes: Database references
• Version 1.3: 2024-01-17
  Changes: Data collection, Database references, Refinement description
