6DUS | pdb_00006dus

Structure of Salmonella Effector SseK3 E258Q mutant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.225 (Depositor), 0.227 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.178 (DCC)
  • R-Value Observed:
    0.180 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6DUS

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Salmonella Effectors SseK1 and SseK3 Target Death Domain Proteins in the TNF and TRAIL Signaling Pathways.

Newson, J.P.M.Scott, N.E.Yeuk Wah Chung, I.Wong Fok Lung, T.Giogha, C.Gan, J.Wang, N.Strugnell, R.A.Brown, N.F.Cygler, M.Pearson, J.S.Hartland, E.L.

(2019) Mol Cell Proteomics 18: 1138-1156

  • DOI: https://doi.org/10.1074/mcp.RA118.001093
  • Primary Citation Related Structures:
    6CGI, 6DUS

  • PubMed Abstract:

    Strains of Salmonella utilize two distinct type three secretion systems to deliver effector proteins directly into host cells. The Salmonella effectors SseK1 and SseK3 are arginine glycosyltransferases that modify mammalian death domain containing proteins with N -acetyl glucosamine (GlcNAc) when overexpressed ectopically or as recombinant protein fusions. Here, we combined Arg-GlcNAc glycopeptide immunoprecipitation and mass spectrometry to identify host proteins GlcNAcylated by endogenous levels of SseK1 and SseK3 during Salmonella infection. We observed that SseK1 modified the mammalian signaling protein TRADD, but not FADD as previously reported. Overexpression of SseK1 greatly broadened substrate specificity, whereas ectopic co-expression of SseK1 and TRADD increased the range of modified arginine residues within the death domain of TRADD. In contrast, endogenous levels of SseK3 resulted in modification of the death domains of receptors of the mammalian TNF superfamily, TNFR1 and TRAILR, at residues Arg 376 and Arg 293 respectively. Structural studies on SseK3 showed that the enzyme displays a classic GT-A glycosyltransferase fold and binds UDP-GlcNAc in a narrow and deep cleft with the GlcNAc facing the surface. Together our data suggest that salmonellae carrying sseK1 and sseK3 employ the glycosyltransferase effectors to antagonise different components of death receptor signaling.


  • Organizational Affiliation
    • From the ‡Department of Microbiology and Immunology, University of Melbourne at the Peter Doherty Institute for Infection and Immunity, Melbourne, Victoria, Australia.

Macromolecule Content

  • Total Structure Weight: 72.09 kDa
  • Atom Count: 5,155
  • Modeled Residue Count: 615
  • Deposited Residue Count: 620
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Type III secretion system effector protein
A, B
310Salmonella enterica subsp. enterica serovar Typhimurium str. SL1344Mutation(s): 1
Gene Names: sseK3SL1344_1928
UniProt
Find proteins for A0A0H3NMP8 (Salmonella typhimurium (strain SL1344))
Explore A0A0H3NMP8
Go to UniProtKB:  A0A0H3NMP8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0H3NMP8
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
UDP

Query on UDP



Download:Ideal Coordinates CCD File
C [auth A],
J [auth B]
URIDINE-5'-DIPHOSPHATE
C9 H14 N2 O12 P2
XCCTYIAWTASOJW-XVFCMESISA-N
NAG

Query on NAG



Download:Ideal Coordinates CCD File
D [auth A],
K [auth B]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
TRS

Query on TRS



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
MPD

Query on MPD



Download:Ideal Coordinates CCD File
H [auth A],
I [auth A]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A],
L [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.225 (Depositor), 0.227 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.178 (DCC)
  • R-Value Observed: 0.180 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.49α = 90
b = 107.12β = 90
c = 74.73γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
AutoSolphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)Canada--

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-18
    Type: Initial release
  • Version 1.1: 2019-06-26
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-08
    Changes: Author supporting evidence
  • Version 1.3: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.4: 2024-03-13
    Changes: Data collection, Database references, Structure summary
