6DJ8 | pdb_00006dj8

Structure of DNA polymerase III subunit beta from Borrelia burgdorferi in complex with a natural product

• PDB DOI: https://doi.org/10.2210/pdb6DJ8/pdb

• Classification: DNA BINDING PROTEIN
• Organism(s): Borreliella burgdorferi B31, Streptomyces
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2018-05-24 Released: 2019-05-29
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:
  0.235 (Depositor), 0.238 (DCC)
• R-Value Work:
  0.202 (Depositor), 0.204 (DCC)
• R-Value Observed:
  0.203 (Depositor)

Literature

Structure of DNA polymerase III subunit beta from Borrelia burgdorferi in complex with a natural product

Conrady, D.G., Abendroth, J., Higgins, T.W., Lorimer, D.D., Horanyi, P.S., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 4-mer - A2B2 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 4-mer - A2B1C1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 93.68 kDa
• Atom Count: 6,451
• Modeled Residue Count: 782
• Deposited Residue Count: 808
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta sliding clamp	A, B	393	Borreliella burgdorferi B31	Mutation(s): 0  Gene Names: dnaN, BB_0438
UniProt
Find proteins for P33761 (Borreliella burgdorferi (strain ATCC 35210 / DSM 4680 / CIP 102532 / B31)) Explore P33761  Go to UniProtKB:  P33761

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Natural product peptide	C, D	11	Streptomyces	Mutation(s): 0

Small Molecules

Modified Residues  3 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MLU	C, D	D-PEPTIDE LINKING	C7 H15 N O2		--
MP8	C, D	L-PEPTIDE LINKING	C6 H11 N O2		PRO
MVA	C, D	L-PEPTIDE LINKING	C6 H13 N O2		VAL
NZC	C, D	L-PEPTIDE LINKING	C5 H11 N O3		THR

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_002311	C, D	ACE-MVA-MP8-NZC-LEU-MP8-LEU-MVA-PRO-MLU-GLY	Peptide-like / Inhibitor

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:  0.235 (Depositor), 0.238 (DCC)
• R-Value Work:  0.202 (Depositor), 0.204 (DCC)
• R-Value Observed: 0.203 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36dj8

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.38	α = 90
b = 68.29	β = 113.7
c = 86.32	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHENIX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-05-29
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2019-05-29
  Type: Initial release

• Version 1.1: 2019-06-26
  Changes: Advisory, Data collection, Derived calculations
• Version 1.2: 2019-07-17
  Changes: Data collection, Derived calculations, Structure summary
• Version 1.3: 2025-04-02
  Changes: Data collection, Database references, Derived calculations, Structure summary
