6CYS

Crystal structure analysis of the D150G mutant of Superoxide Dismutase from Trichoderma reesei

• PDB DOI: https://doi.org/10.2210/pdb6CYS/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Trichoderma reesei QM6a
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2018-04-06 Released: 2018-10-10
• Deposition Author(s): Mendoza Rengifo, E., Garratt, R.C., Ferreira Jr., J.R.S.
• Funding Organization(s): Sao Paulo Research Foundation (FAPESP)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.191
• R-Value Work: 0.160
• R-Value Observed: 0.162

Literature

Crystal structure analysis of the D150G mutant of Superoxide Dismutase from Trichoderma reesei

Mendoza Rengifo, E., Garratt, R.C., Ferreira Jr., J.R.S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 92.51 kDa
• Atom Count: 7,516
• Modelled Residue Count: 836
• Deposited Residue Count: 844
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Superoxide dismutase	A, B, C, D	211	Trichoderma reesei QM6a	Mutation(s): 1  Gene Names: TRIREDRAFT_66345 EC: 1.15.1.1
UniProt
Find proteins for G0RQS7 (Hypocrea jecorina (strain QM6a)) Explore G0RQS7  Go to UniProtKB:  G0RQS7

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FE (Subject of Investigation/LOI)	E [auth A], F [auth B], G [auth C], H [auth D]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.191
• R-Value Work: 0.160
• R-Value Observed: 0.162
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.04	α = 90
b = 82.01	β = 90
c = 133.61	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
iMOSFLM	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2018-10-10
Deposition Author(s): Mendoza Rengifo, E., Garratt, R.C., Ferreira Jr., J.R.S.

---

Funding Organization	Location	Grant Number
Sao Paulo Research Foundation (FAPESP)	Brazil	2014/01855-2

Revision History

• Version 1.0: 2018-10-10
  Type: Initial release

• Version 1.1: 2020-01-01
  Changes: Author supporting evidence, Structure summary
• Version 1.2: 2024-03-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
