6A7S

Ca2+-independent C-type lectin SPL-2 from Saxidomus purpuratus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.179
  • R-Value Observed: 0.181

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Novel Ca2+-independent carbohydrate recognition of the C-type lectins, SPL-1 and SPL-2, from the bivalve Saxidomus purpuratus.

Unno, H.Itakura, S.Higuchi, S.Goda, S.Yamaguchi, K.Hatakeyama, T.

(2019) Protein Sci 28: 766-778

  • DOI: https://doi.org/10.1002/pro.3592
  • Primary Citation of Related Structures:
    6A7S, 6A7T

  • PubMed Abstract:

    Novel Ca 2+ -independent C-type lectins, SPL-1 and SPL-2, were purified from the bivalve Saxidomus purpuratus. They are composed of dimers with either identical (SPL-2 composed of two B-chains) or distinct (SPL-1 composed of A- and B-chains) polypeptide chains, and show affinity for N-acetylglucosamine (GlcNAc)- and N-acetylgalactosamine (GalNAc)-containing carbohydrates, but not for glucose or galactose. A database search for sequence similarity suggested that they belong to the C-type lectin family. X-ray crystallographic analysis revealed definite structural similarities between their subunits and the carbohydrate-recognition domain (CRD) of the C-type lectin family. Nevertheless, these lectins (especially SPL-2) showed Ca 2+ -independent binding affinity for GlcNAc and GalNAc. The crystal structure of SPL-2/GalNAc complex revealed that bound GalNAc was mainly recognized via its acetamido group through stacking interactions with Tyr and His residues and hydrogen bonds with Asp and Asn residues, while widely known carbohydrate-recognition motifs among the C-type CRD (the QPD [Gln-Pro-Asp] and EPN [Glu-Pro-Asn] sequences) are not involved in the binding of the carbohydrate. Carbohydrate-binding specificities of individual A- and B-chains were examined by glycan array analysis using recombinant lectins produced from Escherichia coli cells, where both subunits preferably bound oligosaccharides having terminal GlcNAc or GalNAc with α-glycosidic linkages with slightly different specificities.


  • Organizational Affiliation

    Biomolecular Chemistry Laboratory, Graduate School of Engineering, Nagasaki University, Nagasaki 852-8521, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
N-acetylglucosamine-specific lectinA [auth B]159Saxidomus purpurataMutation(s): 0
UniProt
Find proteins for A0A2Z6G7U3 (Saxidomus purpurata)
Explore A0A2Z6G7U3
Go to UniProtKB:  A0A2Z6G7U3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2Z6G7U3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.179
  • R-Value Observed: 0.181
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.235α = 90
b = 91.235β = 90
c = 48.791γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapan25450133
Japan Society for the Promotion of ScienceJapan17K07760
Japan Society for the Promotion of ScienceJapan26450128
Japan Society for the Promotion of ScienceJapan15K06977

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-20
    Type: Initial release
  • Version 1.1: 2019-04-03
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.3: 2024-11-20
    Changes: Data collection, Database references, Structure summary
