5ZT9 | pdb_00005zt9

SirB from Bacillus subtilis with Ni2+

PDB DOI: https://doi.org/10.2210/pdb5ZT9/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Bacillus subtilis subsp. subtilis str. 168
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2018-05-02 Released: 2019-06-12
Deposition Author(s): Fujishiro, T.
Funding Organization(s): Japan Society for the Promotion of Science

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free:
0.245 (Depositor), 0.245 (DCC)
R-Value Work:
0.212 (Depositor), 0.213 (DCC)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5ZT9

This is version 1.1 of the entry. See complete history.

Literature

A route for metal acquisition for chelatase reaction catalyzed by SirB from Bacillus subtilis

Fujishiro, T.

To be published.

Macromolecule Content

Total Structure Weight: 60.71 kDa
Atom Count: 4,043
Modeled Residue Count: 510
Deposited Residue Count: 546
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sirohydrochlorin ferrochelatase	A, B	273	Bacillus subtilis subsp. subtilis str. 168	Mutation(s): 0 Gene Names: sirB, ylnE, BSU15620 EC: 4.99.1.4
UniProt
Find proteins for O34632 (Bacillus subtilis (strain 168)) Explore O34632 Go to UniProtKB: O34632
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O34632
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NI Query on NI Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain E [auth B] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain F [auth B] MOL2 format, chain E [auth B] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain F [auth B] mmCIF format, chain E [auth B] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A], E [auth B], F [auth B]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free: 0.245 (Depositor), 0.245 (DCC)
R-Value Work: 0.212 (Depositor), 0.213 (DCC)
R-Value Observed: 0.214 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.73	α = 90
b = 53.7	β = 107.66
c = 78.02	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2019-06-12

Deposition Author(s):

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science	Japan	17K14510

Revision History (Full details and data files)

Version 1.0: 2019-06-12
Type: Initial release
Version 1.1: 2023-11-22
Changes: Data collection, Database references, Derived calculations, Refinement description
