5Z90

BRD4 Bromodomain 1 with an inhibitor

PDB DOI: https://doi.org/10.2210/pdb5Z90/pdb

Classification: TRANSCRIPTION/INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2018-02-01 Released: 2019-02-06
Deposition Author(s): Xiao, S., Chen, S., Chen, H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.264
R-Value Work: 0.208
R-Value Observed: 0.211

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

BRD4 Bromodomain 1 with an inhibitor

Xiao, S., Chen, S., Chen, H.

To be published.

Macromolecule Content

Total Structure Weight: 15.43 kDa
Atom Count: 1,131
Modelled Residue Count: 127
Deposited Residue Count: 127
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	127	Homo sapiens	Mutation(s): 0 Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885 Go to UniProtKB: O60885
PHAROS: O60885 GTEx: ENSG00000141867
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O60885
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
99U (Subject of Investigation/LOI) Query on 99U Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	1-ethyl-6-pyrrolidin-1-ylsulfonyl-benzo[cd]indol-2-one C₁₇ H₁₈ N₂ O₃ S HTONIJRZZRKKQF-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Binding Affinity Annotations
ID	Source	Binding Affinity
99U	BindingDB: 5Z90	IC50: min: 1910, max: 6830 (nM) from 2 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.264
R-Value Work: 0.208
R-Value Observed: 0.211
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 33.079	α = 90
b = 47.695	β = 90
c = 78.808	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2019-02-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2019-02-06
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
