5YTN | pdb_00005ytn

C135A mutant of copper-containing nitrite reductase from Geobacillus thermodenitrificans in complex with peroxide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free:
    0.227 (Depositor), 0.223 (DCC)
  • R-Value Work:
    0.193 (Depositor)
  • R-Value Observed:
    0.195 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5YTN

This is version 1.1 of the entry. See complete history

Literature

Crystallographic study of dioxygen chemistry in a copper-containing nitrite reductase from Geobacillus thermodenitrificans.

Fukuda, Y.Matsusaki, T.Tse, K.M.Mizohata, E.Murphy, M.E.P.Inoue, T.

(2018) Acta Crystallogr D Struct Biol 74: 769-777

  • DOI: https://doi.org/10.1107/S2059798318010082
  • Primary Citation Related Structures:
    5YTL, 5YTM, 5YTN

  • PubMed Abstract:

    Copper-containing nitrite reductases (CuNIRs) are multifunctional enzymes that catalyse the one-electron reduction of nitrite (NO 2 - ) to nitric oxide (NO) and the two-electron reduction of dioxygen (O 2 ) to hydrogen peroxide (H 2 O 2 ). In contrast to the mechanism of nitrite reduction, that of dioxygen reduction is poorly understood. Here, results from anaerobic synchrotron-radiation crystallography (SRX) and aerobic in-house radiation crystallography (iHRX) with a CuNIR from the thermophile Geobacillus thermodenitrificans (GtNIR) support the hypothesis that the dioxygen present in an aerobically manipulated crystal can bind to the catalytic type 2 copper (T2Cu) site of GtNIR during SRX experiments. The anaerobic SRX structure showed a dual conformation of one water molecule as an axial ligand in the T2Cu site, while previous aerobic SRX GtNIR structures were refined as diatomic molecule-bound states. Moreover, an SRX structure of the C135A mutant of GtNIR with peroxide bound to the T2Cu atom was determined. The peroxide molecule was mainly observed in a side-on binding manner, with a possible minor end-on conformation. The structures provide insights into dioxygen chemistry in CuNIRs and hence help to unmask the other face of CuNIRs.


  • Organizational Affiliation
    • Department of Applied Chemistry, Graduate School of Engineering, Osaka University, 2-1 Yamadaoka, Suita, Osaka 565-0871, Japan.

Macromolecule Content

  • Total Structure Weight: 35.83 kDa
  • Atom Count: 2,754
  • Modeled Residue Count: 298
  • Deposited Residue Count: 323
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Copper-containing nitrite reductase323Geobacillus thermodenitrificansMutation(s): 1
Gene Names: nirKGTHT12_00198
EC: 1.7.2.1

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free:  0.227 (Depositor), 0.223 (DCC)
  • R-Value Work:  0.193 (Depositor)
  • R-Value Observed: 0.195 (Depositor)
Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 115.566α = 90
b = 115.566β = 90
c = 84.013γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapan--

Revision History  (Full details and data files)

  • Version 1.0: 2018-08-22
    Type: Initial release
  • Version 1.1: 2024-03-27
    Changes: Data collection, Database references, Derived calculations
