5YSK | pdb_00005ysk

SdeA mART-C domain EE/AA apo


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.261 (Depositor), 0.262 (DCC)
  • R-Value Work:
    0.185 (Depositor), 0.185 (DCC)
  • R-Value Observed:
    0.193 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5YSK

This is version 1.1 of the entry. See complete history

Literature

Structural and Biochemical Study of the Mono-ADP-Ribosyltransferase Domain of SdeA, a Ubiquitylating/Deubiquitylating Enzyme from Legionella pneumophila

Kim, L.Kwon, D.H.Kim, B.H.Kim, J.Park, M.R.Park, Z.Y.Song, H.K.

(2018) J Mol Biology 430: 2843-2856

  • DOI: https://doi.org/10.1016/j.jmb.2018.05.043
  • Primary Citation Related Structures:
    5YSI, 5YSJ, 5YSK

  • PubMed Abstract:

    Conventional ubiquitylation occurs through an ATP-dependent three-enzyme cascade (E1, E2, and E3) that mediates the covalent conjugation of the C-terminus of ubiquitin to a lysine on the substrate. SdeA, which belongs to the SidE effector family of Legionella pneumophila, can transfer ubiquitin to endoplasmic reticulum-associated Rab-family GTPases in a manner independent of E1 and E2 enzymes. The novel ubiquitin-modifying enzyme SdeA utilizes NAD + as a cofactor to attach ubiquitin to a serine residue of the substrate. Here, to elucidate the coupled enzymatic reaction of NAD+ hydrolysis and ADP-ribosylation of ubiquitin in SdeA, we characterized the mono-ADP-ribosyltransferase domain of SdeA and show that it consists of two sub-domains termed mART-N and mART-C. The crystal structure of the mART-C domain of SdeA was also determined in free form and in complex with NAD + at high resolution. Furthermore, the spatial orientations of the N-terminal deubiquitylase, phosphodiesterase, mono-ADP-ribosyltransferase, and C-terminal coiled-coil domains within the 180-kDa full-length SdeA were determined. These results provide insight into the unusual ubiquitylation mechanism of SdeA and expand our knowledge on the structure-function of mono-ADP-ribosyltransferases.


  • Organizational Affiliation
    • Department of Life Sciences, Korea University, 145 Anam-ro, Seongbuk-gu, Seoul 02841, Korea.

Macromolecule Content

  • Total Structure Weight: 67.69 kDa
  • Atom Count: 4,427
  • Modeled Residue Count: 550
  • Deposited Residue Count: 608
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubiquitinating/deubiquitinating enzyme SdeA
A, B, C, D
152Legionella pneumophila subsp. pneumophila str. Philadelphia 1Mutation(s): 2
Gene Names: sdeAlpg2157
EC: 3.4.22 (PDB Primary Data), 2.3.2 (UniProt), 2.4.2.31 (UniProt)
UniProt
Find proteins for Q5ZTK4 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513))
Explore Q5ZTK4
Go to UniProtKB:  Q5ZTK4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5ZTK4
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.261 (Depositor), 0.262 (DCC)
  • R-Value Work:  0.185 (Depositor), 0.185 (DCC)
  • R-Value Observed: 0.193 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.75α = 90
b = 85.36β = 97.11
c = 70.795γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-08-29
    Type: Initial release
  • Version 1.1: 2024-10-16
    Changes: Data collection, Database references, Structure summary
