5Y9Y | pdb_00005y9y

Crystal structure of the Kdo hydroxylase KdoO, a non-heme Fe(II) alphaketoglutarate dependent dioxygenase in complex with succinate and Co(II)

PDB DOI: https://doi.org/10.2210/pdb5Y9Y/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Methylacidiphilum infernorum V4
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-08-29 Released: 2018-10-31
Deposition Author(s): Chung, H.S., Pemble, C.W., Joo, S.H., Raetz, C.R.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.194 (Depositor), 0.187 (DCC)
R-Value Work:
0.159 (Depositor), 0.159 (DCC)
R-Value Observed:
0.161 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5Y9Y

This is version 1.1 of the entry. See complete history.

Literature

Biochemical and structural insights of Fe(II)/alpha-ketoglutarate/O2-dependent dioxygenase, KdoO from Methylacidiphilum infernorum V4

Chung, H.S., Pemble IV, C.W., Joo, S.H.

To be published.

Macromolecule Content

Total Structure Weight: 37.94 kDa
Atom Count: 2,743
Modeled Residue Count: 297
Deposited Residue Count: 318
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein KdoO	A	318	Methylacidiphilum infernorum V4	Mutation(s): 0 Gene Names: Minf_1012
UniProt
Find proteins for B3DUR4 (Methylacidiphilum infernorum (isolate V4)) Explore B3DUR4 Go to UniProtKB: B3DUR4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B3DUR4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A]	E [auth A], F [auth A], G [auth A], H [auth A], I [auth A]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
SIN Query on SIN Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	SUCCINIC ACID C₄ H₆ O₄ KDYFGRWQOYBRFD-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain N [auth A] SDF format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A]	N [auth A], O [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain N [auth A] Focus chain O [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A]	J [auth A], K [auth A], L [auth A], M [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A]
CO Query on CO Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	COBALT (II) ION Co XLJKHNWPARRRJB-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain P [auth A] MOL2 format, chain P [auth A] mmCIF format, chain P [auth A]	P [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain P [auth A] Interactions & Density Focus chain P [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.194 (Depositor), 0.187 (DCC)
R-Value Work: 0.159 (Depositor), 0.159 (DCC)
R-Value Observed: 0.161 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.762	α = 90
b = 59.316	β = 90
c = 116.429	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
HKL-2000	data reduction
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-10-31

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-10-31
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references, Derived calculations
