5Y1V

Crystal structure of Plasmodium falciparum aminopeptidase N in complex with (S)-2-(3-(2,6-diethylphenyl)ureido)- N-hydroxy-4-methylpentanamide

• PDB DOI: https://doi.org/10.2210/pdb5Y1V/pdb

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Plasmodium falciparum FcB1/Columbia
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-07-21 Released: 2018-08-01
• Deposition Author(s): Marapaka, A.K., Zhang, Y., Addlagatta, A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.62 Å
• R-Value Free: 0.202
• R-Value Work: 0.169
• R-Value Observed: 0.170

Starting Model: experimental

Literature

Crystal structure of Plasmodium falciparum aminopeptidase N in complex with (S)-2-(3-(2,6-diethylphenyl)ureido)- N-hydroxy-4-methylpentanamide

Marapaka, A.K., Addlagatta, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 106.91 kDa
• Atom Count: 8,113
• Modelled Residue Count: 890
• Deposited Residue Count: 914
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
M1 family aminopeptidase	A	914	Plasmodium falciparum FcB1/Columbia	Mutation(s): 0  EC: 3.4.11
UniProt
Find proteins for O96935 (Plasmodium falciparum (isolate 3D7)) Explore O96935  Go to UniProtKB:  O96935

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
8LO	E [auth A]	(2R)-2-[(2,6-diethylphenyl)carbamoylamino]-4-methyl-N-oxidanyl-pentanamide C17 H27 N3 O3 ISOSJSYJSANOPI-CQSZACIVSA-N
GOL	F [auth A], G [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG	C [auth A], D [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.62 Å
• R-Value Free: 0.202
• R-Value Work: 0.169
• R-Value Observed: 0.170
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.588	α = 90
b = 109.394	β = 90
c = 112.63	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data collection
SCALEPACK	data scaling
MOLREP	model building
PDB_EXTRACT	data extraction
DENZO	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-08-01
Deposition Author(s): Marapaka, A.K., Zhang, Y., Addlagatta, A.

Revision History

• Version 1.0: 2018-08-01
  Type: Initial release

• Version 1.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description
