5XBR

Peroxiredoxin from Pyrococcus horikoshii (sulfonic acid form)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.189
  • R-Value Observed: 0.192

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Alteration of molecular assembly of peroxiredoxins from hyperthermophilic archaea

Nakamura, T.Oshima, M.Yasuda, M.Shimamura, A.Morita, J.Uegaki, K.

(2017) J Biochem 162: 415-422

  • DOI: https://doi.org/10.1093/jb/mvx045
  • Primary Citation of Related Structures:
    5XBQ, 5XBR, 5XBS

  • PubMed Abstract:

    Peroxiredoxin from Pyrococcus horikoshii (PhPrx) is a decameric protein formed by ring-type assembly of five dimers. To engineer the quaternary structure of PhPrx, we created a mutant PhPrx (PhPrx6m) by introducing six point mutations designed to dissociate PhPrx into dimers. Although PhPrx6m was a dimer in solution, the six dimers assembled into a dodecamer following crystallization. In the crystal structure, PhPrx6m was overoxidized, and the peroxidatic cysteine was in sulfonic acid form and two cysteines in the C-terminal region were linked by an intramolecular disulfide bond. Thus, we characterized the wild-type PhPrx overoxidized by hydrogen peroxide (PhPrxPer). Analytical ultracentrifugation showed that PhPrxPer had a higher molecular mass in solution than PhPrx. This was confirmed by analysis of the crystal structure of PhPrxPer, which was found to form a ring-type dodecamer composed of six dimers. The monomeric structures of PhPrx6m and PhPrxPer differed from that of PhPrx in the relative orientation of two domains, reflecting the number of dimers in the ring-type assembly. Unlike PhPrx, homologous peroxiredoxin from Aeropyrum pernix (ApPrx) did not undergo hexameric association. This property can be explained by the stronger connection between the two domains in ApPrx due to its C-terminal extension relative to PhPrx.


  • Organizational Affiliation

    National Institute of Advanced Industrial Science and Technology, Ikeda, Osaka 563-8577, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Peroxiredoxin
A, B
216Pyrococcus horikoshii OT3Mutation(s): 0
Gene Names: ahpCPH1217
EC: 1.11.1.15 (PDB Primary Data), 1.11.1.24 (UniProt)
UniProt
Find proteins for O58966 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3))
Explore O58966
Go to UniProtKB:  O58966
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO58966
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
OCS
Query on OCS
A, B
L-PEPTIDE LINKINGC3 H7 N O5 SCYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.189
  • R-Value Observed: 0.192
  • Space Group: P 6
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 140.466α = 90
b = 140.466β = 90
c = 48.023γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Education, Culture, Sports, Science and TechnologyJapan24109017
Japan Society for the Promotion of ScienceJapan15K01815

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-31
    Type: Initial release
