5X73

The crystal Structure PDE delta in complex with R-p9

• PDB DOI: https://doi.org/10.2210/pdb5X73/pdb

• Classification: LIPID BINDING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-02-23 Released: 2017-10-04
• Deposition Author(s): Jiang, Y., Zhuang, C., Chen, L., Wang, R., Wang, F., Sheng, C.
• Funding Organization(s): National Basic Research Program of China

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.245
• R-Value Work: 0.195
• R-Value Observed: 0.198

Starting Model: experimental

Literature

Structural Biology-Inspired Discovery of Novel KRAS-PDE delta Inhibitors

Jiang, Y., Zhuang, C., Chen, L., Lu, J., Dong, G., Miao, Z., Zhang, W., Li, J., Sheng, C.

(2017) J Med Chem 60: 9400-9406

• PubMed: 28929751
• DOI: https://doi.org/10.1021/acs.jmedchem.7b01243
• Primary Citation of Related Structures:
  5X72, 5X73, 5X74


• PubMed Abstract:


  Structural biology is a powerful tool for investigating the stereospecific interactions between a protein and its ligand. Herein, an unprecedented chiral binding pattern was observed for inhibitors of KRAS-PDEδ interactions. Virtual screening and X-ray crystallography studies revealed that two enantiomers of a racemic inhibitor could bind at different sites. Fragment-based drug design was used to identify highly potent PDEδ inhibitors that can be used as promising lead compounds for target validation and antitumor drug development.

---

Organizational Affiliation:

School of Pharmacy, Second Military Medical University , Shanghai 200433, China.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 18.08 kDa
• Atom Count: 1,293
• Modelled Residue Count: 148
• Deposited Residue Count: 150
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Retinal rod rhodopsin-sensitive cGMP 3',5'-cyclic phosphodiesterase subunit delta	A	150	Homo sapiens	Mutation(s): 0  Gene Names: PDE6D, PDED
UniProt & NIH Common Fund Data Resources
Find proteins for O43924 (Homo sapiens) Explore O43924  Go to UniProtKB:  O43924
PHAROS:  O43924 GTEx:  ENSG00000156973

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
P59	B [auth A], C [auth A]	(2R)-2-(2-fluorophenyl)-3-phenyl-1,2-dihydroquinazolin-4-one C20 H15 F N2 O UMMDFHVNOCVOCD-LJQANCHMSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.245
• R-Value Work: 0.195
• R-Value Observed: 0.198
• Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.55	α = 90
b = 55.55	β = 90
c = 115.34	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2017-10-04
Deposition Author(s): Jiang, Y., Zhuang, C., Chen, L., Wang, R., Wang, F., Sheng, C.

---

Funding Organization	Location	Grant Number
National Basic Research Program of China	China	2014CB541800

Revision History

• Version 1.0: 2017-10-04
  Type: Initial release

• Version 1.1: 2017-12-06
  Changes: Database references
• Version 1.2: 2023-11-22
  Changes: Data collection, Database references, Refinement description
