5VCT | pdb_00005vct

Crystal structure of UTP-glucose-1-phosphate uridylyltransferase from Burkholderia ambifaria

PDB DOI: https://doi.org/10.2210/pdb5VCT/pdb

Classification: TRANSFERASE
Organism(s): Burkholderia ambifaria MC40-6
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-03-31 Released: 2017-04-12
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.196 (Depositor), 0.197 (DCC)
R-Value Work:
0.168 (Depositor), 0.171 (DCC)
R-Value Observed:
0.170 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5VCT

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of UTP-glucose-1-phosphate uridylyltransferase from Burkholderia ambifaria

Abendroth, J., Higgins, T.W., Dranow, D.M., Lorimer, D.D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 33.49 kDa
Atom Count: 2,457
Modeled Residue Count: 282
Deposited Residue Count: 302
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
UTP--glucose-1-phosphate uridylyltransferase	A	302	Burkholderia ambifaria MC40-6	Mutation(s): 0 Gene Names: BamMC406_1359 EC: 2.7.7.9
UniProt
Find proteins for B1YNX3 (Burkholderia ambifaria (strain MC40-6)) Explore B1YNX3 Go to UniProtKB: B1YNX3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B1YNX3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.196 (Depositor), 0.197 (DCC)
R-Value Work: 0.168 (Depositor), 0.171 (DCC)
R-Value Observed: 0.170 (Depositor)

Diffraction Data:

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.9	α = 90
b = 111.21	β = 90
c = 124.75	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
MOLREP	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-04-12

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2017-04-12
Type: Initial release
Version 1.1: 2023-10-04
Changes: Data collection, Database references, Refinement description
