5V36

1.88 Angstrom Resolution Crystal Structure of Glutathione Reductase from Streptococcus mutans UA159 in Complex with FAD

PDB DOI: https://doi.org/10.2210/pdb5V36/pdb

Classification: HYDROLASE,OXIDOREDUCTASE
Organism(s): Streptococcus mutans UA159
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-03-06 Released: 2017-03-22
Deposition Author(s): Minasov, G., Shuvalova, L., Dubrovska, I., Kiryukhina, O., Grimshaw, S., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free: 0.170
R-Value Work: 0.143
R-Value Observed: 0.144

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

1.88 Angstrom Resolution Crystal Structure of Glutathione Reductase from Streptococcus mutans UA159 in Complex with FAD.

Minasov, G., Shuvalova, L., Dubrovska, I., Kiryukhina, O., Grimshaw, S., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 104.39 kDa
Atom Count: 8,838
Modelled Residue Count: 902
Deposited Residue Count: 906
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutathione reductase	A, B	453	Streptococcus mutans UA159	Mutation(s): 0 Gene Names: gshR, SMU_838 EC: 3.3.1.1 (PDB Primary Data), 1.8.1.7 (PDB Primary Data)
UniProt
Find proteins for Q8DUR5 (Streptococcus mutans serotype c (strain ATCC 700610 / UA159)) Explore Q8DUR5 Go to UniProtKB: Q8DUR5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8DUR5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD Query on FAD Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain CA [auth B] MOL2 format, chain C [auth A] MOL2 format, chain CA [auth B] mmCIF format, chain C [auth A] mmCIF format, chain CA [auth B]	C [auth A], CA [auth B]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain C [auth A] Focus chain CA [auth B] Interactions & Density Focus chain C [auth A] Focus chain CA [auth B]
EPE Query on EPE Download Ideal Coordinates CCD File SDF format, chain BA [auth A] MOL2 format, chain BA [auth A] mmCIF format, chain BA [auth A]	BA [auth A]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain BA [auth A] Interactions & Density Focus chain BA [auth A]
BDF Query on BDF Download Ideal Coordinates CCD File SDF format, chain YA [auth B] MOL2 format, chain YA [auth B] mmCIF format, chain YA [auth B]	YA [auth B]	beta-D-fructopyranose C₆ H₁₂ O₆ LKDRXBCSQODPBY-ARQDHWQXSA-N		Interactions Focus chain YA [auth B] Interactions & Density Focus chain YA [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain IA [auth B] SDF format, chain J [auth A] SDF format, chain JA [auth B] SDF format, chain K [auth A] SDF format, chain KA [auth B] SDF format, chain L [auth A] SDF format, chain LA [auth B] SDF format, chain M [auth A] SDF format, chain MA [auth B] SDF format, chain N [auth A] SDF format, chain NA [auth B] SDF format, chain O [auth A] SDF format, chain OA [auth B] SDF format, chain P [auth A] SDF format, chain PA [auth B] SDF format, chain Q [auth A] SDF format, chain QA [auth B] SDF format, chain R [auth A] SDF format, chain RA [auth B] SDF format, chain S [auth A] SDF format, chain SA [auth B] SDF format, chain T [auth A] SDF format, chain TA [auth B] SDF format, chain U [auth A] SDF format, chain UA [auth B] SDF format, chain V [auth A] SDF format, chain VA [auth B] SDF format, chain W [auth A] SDF format, chain X [auth A] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth B] MOL2 format, chain J [auth A] MOL2 format, chain JA [auth B] MOL2 format, chain K [auth A] MOL2 format, chain KA [auth B] MOL2 format, chain L [auth A] MOL2 format, chain LA [auth B] MOL2 format, chain M [auth A] MOL2 format, chain MA [auth B] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth B] MOL2 format, chain O [auth A] MOL2 format, chain OA [auth B] MOL2 format, chain P [auth A] MOL2 format, chain PA [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain QA [auth B] MOL2 format, chain R [auth A] MOL2 format, chain RA [auth B] MOL2 format, chain S [auth A] MOL2 format, chain SA [auth B] MOL2 format, chain T [auth A] MOL2 format, chain TA [auth B] MOL2 format, chain U [auth A] MOL2 format, chain UA [auth B] MOL2 format, chain V [auth A] MOL2 format, chain VA [auth B] MOL2 format, chain W [auth A] MOL2 format, chain X [auth A] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth B] mmCIF format, chain J [auth A] mmCIF format, chain JA [auth B] mmCIF format, chain K [auth A] mmCIF format, chain KA [auth B] mmCIF format, chain L [auth A] mmCIF format, chain LA [auth B] mmCIF format, chain M [auth A] mmCIF format, chain MA [auth B] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth B] mmCIF format, chain O [auth A] mmCIF format, chain OA [auth B] mmCIF format, chain P [auth A] mmCIF format, chain PA [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain QA [auth B] mmCIF format, chain R [auth A] mmCIF format, chain RA [auth B] mmCIF format, chain S [auth A] mmCIF format, chain SA [auth B] mmCIF format, chain T [auth A] mmCIF format, chain TA [auth B] mmCIF format, chain U [auth A] mmCIF format, chain UA [auth B] mmCIF format, chain V [auth A] mmCIF format, chain VA [auth B] mmCIF format, chain W [auth A] mmCIF format, chain X [auth A]	I [auth A] IA [auth B] J [auth A] JA [auth B] K [auth A] I [auth A], IA [auth B], J [auth A], JA [auth B], K [auth A], KA [auth B], L [auth A], LA [auth B], M [auth A], MA [auth B], N [auth A], NA [auth B], O [auth A], OA [auth B], P [auth A], PA [auth B], Q [auth A], QA [auth B], R [auth A], RA [auth B], S [auth A], SA [auth B], T [auth A], TA [auth B], U [auth A], UA [auth B], V [auth A], VA [auth B], W [auth A], X [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth B] Focus chain T [auth A] Focus chain TA [auth B] Focus chain U [auth A] Focus chain UA [auth B] Focus chain V [auth A] Focus chain VA [auth B] Focus chain W [auth A] Focus chain X [auth A] Interactions & Density Focus chain I [auth A] Focus chain IA [auth B] Focus chain J [auth A] Focus chain JA [auth B] Focus chain K [auth A] Focus chain KA [auth B] Focus chain L [auth A] Focus chain LA [auth B] Focus chain M [auth A] Focus chain MA [auth B] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth B] Focus chain T [auth A] Focus chain TA [auth B] Focus chain U [auth A] Focus chain UA [auth B] Focus chain V [auth A] Focus chain VA [auth B] Focus chain W [auth A] Focus chain X [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain AA [auth A] SDF format, chain WA [auth B] SDF format, chain XA [auth B] SDF format, chain Y [auth A] SDF format, chain Z [auth A] MOL2 format, chain AA [auth A] MOL2 format, chain WA [auth B] MOL2 format, chain XA [auth B] MOL2 format, chain Y [auth A] MOL2 format, chain Z [auth A] mmCIF format, chain AA [auth A] mmCIF format, chain WA [auth B] mmCIF format, chain XA [auth B] mmCIF format, chain Y [auth A] mmCIF format, chain Z [auth A]	AA [auth A], WA [auth B], XA [auth B], Y [auth A], Z [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain AA [auth A] Focus chain WA [auth B] Focus chain XA [auth B] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain WA [auth B] Focus chain XA [auth B] Focus chain Y [auth A] Focus chain Z [auth A]
BME Query on BME Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain DA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain DA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain DA [auth B]	D [auth A], DA [auth B]	BETA-MERCAPTOETHANOL C₂ H₆ O S DGVVWUTYPXICAM-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain DA [auth B] Interactions & Density Focus chain D [auth A] Focus chain DA [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain EA [auth B] SDF format, chain F [auth A] SDF format, chain FA [auth B] SDF format, chain G [auth A] SDF format, chain GA [auth B] SDF format, chain H [auth A] SDF format, chain HA [auth B] MOL2 format, chain E [auth A] MOL2 format, chain EA [auth B] MOL2 format, chain F [auth A] MOL2 format, chain FA [auth B] MOL2 format, chain G [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain H [auth A] MOL2 format, chain HA [auth B] mmCIF format, chain E [auth A] mmCIF format, chain EA [auth B] mmCIF format, chain F [auth A] mmCIF format, chain FA [auth B] mmCIF format, chain G [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain H [auth A] mmCIF format, chain HA [auth B]	E [auth A] EA [auth B] F [auth A] FA [auth B] G [auth A] E [auth A], EA [auth B], F [auth A], FA [auth B], G [auth A], GA [auth B], H [auth A], HA [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B] Interactions & Density Focus chain E [auth A] Focus chain EA [auth B] Focus chain F [auth A] Focus chain FA [auth B] Focus chain G [auth A] Focus chain GA [auth B] Focus chain H [auth A] Focus chain HA [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free: 0.170
R-Value Work: 0.143
R-Value Observed: 0.144
Space Group: P 6₅ 2 2
Diffraction Data: https://doi.org/10.18430/m35v36

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 126.333	α = 90
b = 126.333	β = 90
c = 247.876	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2017-03-22

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2017-03-22
Type: Initial release
Version 1.1: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Data collection, Derived calculations, Structure summary
Version 1.2: 2023-10-04
Changes: Data collection, Database references, Refinement description, Structure summary
