5V0M | pdb_00005v0m

SeMet crystal structure of the Neisseria meningitidis non-core minor pilin PilV in the monoclinic form

• PDB DOI: https://doi.org/10.2210/pdb5V0M/pdb

• Classification: CELL ADHESION
• Organism(s): Neisseria meningitidis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-02-28 Released: 2018-02-28
• Deposition Author(s): Kolappan, S., Craig, L.
• Funding Organization(s): Canadian Institutes of Health Research (CIHR)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.41 Å
• R-Value Free:
  0.206 (Depositor), 0.208 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.175 (DCC)
• R-Value Observed:
  0.174 (Depositor)

Starting Model: experimental

Literature

Crystal structure of PilV from Neisseria meningitidis

Kolappan, S., Craig, L.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 11.22 kDa
• Atom Count: 947
• Modeled Residue Count: 98
• Deposited Residue Count: 98
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Type IV pilin protein	A	98	Neisseria meningitidis	Mutation(s): 0  Gene Names: A6L27_01160
UniProt
Find proteins for A0A9K2KQ72 (Neisseria meningitidis serogroup C (strain 8013)) Explore A0A9K2KQ72  Go to UniProtKB:  A0A9K2KQ72

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	B [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.41 Å
• R-Value Free:  0.206 (Depositor), 0.208 (DCC)
• R-Value Work:  0.172 (Depositor), 0.175 (DCC)
• R-Value Observed: 0.174 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.32	α = 90
b = 21.8	β = 104.24
c = 83.83	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2018-02-28
Deposition Author(s): Kolappan, S., Craig, L.

---

Funding Organization	Location	Grant Number
Canadian Institutes of Health Research (CIHR)	Canada	MOP125959

Revision History

• Version 1.0: 2018-02-28
  Type: Initial release

• Version 1.1: 2020-01-08
  Changes: Author supporting evidence
• Version 1.2: 2023-10-04
  Changes: Data collection, Database references, Refinement description
• Version 1.3: 2023-11-15
  Changes: Data collection
• Version 1.4: 2024-10-16
  Changes: Structure summary
