5UPN | pdb_00005upn

Crystal structure of BhGH81 mutant in complex with laminaro-tetraose

PDB DOI: https://doi.org/10.2210/pdb5UPN/pdb

Classification: HYDROLASE
Organism(s): Halalkalibacterium halodurans C-125
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2017-02-03 Released: 2017-06-28
Deposition Author(s): Pluvinage, B., Boraston, A.B.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.167 (Depositor), 0.180 (DCC)
R-Value Work:
0.149 (Depositor), 0.160 (DCC)
R-Value Observed:
0.150 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history.

Literature

The quaternary structure of beta-1,3-glucan contributes to its recognition and hydrolysis by a multimodular family 81 glycoside hydrolase

Pluvinage, B., Fillo, A., Massel, P., Boraston, A.B.

(2017) Structure

Macromolecule Content

Total Structure Weight: 88.46 kDa
Atom Count: 7,165
Modeled Residue Count: 752
Deposited Residue Count: 753
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BH0236 protein	A	753	Halalkalibacterium halodurans C-125	Mutation(s): 1 Gene Names: BH0236 EC: 3.2.1.39
UniProt
Find proteins for Q9KG76 (Halalkalibacterium halodurans (strain ATCC BAA-125 / DSM 18197 / FERM 7344 / JCM 9153 / C-125)) Explore Q9KG76 Go to UniProtKB: Q9KG76
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9KG76
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-glucopyranose-(1-3)-beta-D-glucopyranose	B, C	2		N/A	Interactions Focus chain B Focus chain C Interactions & Density Focus chain B Focus chain C
Glycosylation Resources
GlyTouCan: G36535HU GlyCosmos: G36535HU

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose	D	4		N/A	Interactions Focus chain D Interactions & Density Focus chain D
Glycosylation Resources
GlyTouCan: G87841AX GlyCosmos: G87841AX GlyGen: G87841AX

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
BGC Query on BGC Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	F [auth A], G [auth A]	beta-D-glucopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-VFUOTHLCSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A]
GLC Query on GLC Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	alpha-D-glucopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-DVKNGEFBSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
PO4 Query on PO4 Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A]	H [auth A] I [auth A] J [auth A] K [auth A] L [auth A] H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] SDF format, chain V [auth A] SDF format, chain W [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] MOL2 format, chain V [auth A] MOL2 format, chain W [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A] mmCIF format, chain V [auth A] mmCIF format, chain W [auth A]	Q [auth A] R [auth A] S [auth A] T [auth A] U [auth A] Q [auth A], R [auth A], S [auth A], T [auth A], U [auth A], V [auth A], W [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Interactions & Density Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A]

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900024 Query on PRD_900024	B, C	beta-laminaribiose	Oligosaccharide / Antimicrobial		Interactions Focus chain B Focus chain C Interactions & Density Focus chain B Focus chain C

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.167 (Depositor), 0.180 (DCC)
R-Value Work: 0.149 (Depositor), 0.160 (DCC)
R-Value Observed: 0.150 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.61	α = 90
b = 95.39	β = 90
c = 158.27	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MOSFLM	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2017-06-28

Deposition Author(s):

Pluvinage, B.

Boraston, A.B.

Revision History (Full details and data files)

Version 1.0: 2017-06-28
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2023-10-04
Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
